672GP John Deere Construction 672GP Specifications & Technical Data (2017—2026)

Weight: 17.14t – Standard tyres: 14 R24 – Drive: A – Transport length: 8.89m – Transport width: 2.49m – Transport height: 3.4m

672GP

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 672GP John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 17.14 t

Standard tyres: 14 R24

Drive: A

Transport length: 8.89 m

Transport width: 2.49 m

Transport height: 3.4 m

Mouldboard width: 3.66 m

Travel speed: 45.5 km/h

Turning radius outside: 7.21 m

Model series: G

Engine manuf.: John Deere

Engine type: PowerTech PSS 9.0L

Engine power: 190 kW

Displacement: 9 l

Max. torque: 1292 Nm

No. of cylinders: 6

Emission level: Tier 4f/EU V

More technical details, like: steering mode, front blade width, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: No

Download datasheets (PDF)

John Deere Construction 672GP FAQ

When was the John Deere Construction 672GP manufactured?

The John Deere Construction 672GP was first produced in 2017.

How much does the John Deere Construction 672GP weigh?

The John Deere Construction 672GP weighs 17.14 tons.

What are the transport dimensions of the John Deere Construction 672GP grader?

The John Deere Construction 672GP grader has a transport length of 8.89 meters, a width of 2.49 meters, and a height of 3.4 meters.

What is the travel speed of the John Deere Construction 672GP grader?

The John Deere Construction 672GP grader has a travel speed of 45.5 km/h.

What are the undercarriage specifications of the John Deere Construction 672GP?

The John Deere Construction 672GP features an all-wheel drive system and comes equipped with standard 14 R24 tyres.

What is the turning radius of the John Deere Construction 672GP grader?

The John Deere Construction 672GP grader has an outside turning radius of 7.21 meters.

What is the mouldboard width of the John Deere Construction 672GP grader?

The John Deere Construction 672GP grader has a mouldboard width of 3.66 meters.

How much is a John Deere Construction 672GP Grader (2017u20132025) worth?

The residual value of the John Deere Construction 672GP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
