Technical specs - 620GP John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 14.9 t

Standard tyres: 17.5 R25

Transport length: 8.89 m

Transport width: 2.49 m

Transport height: 3.4 m

Mouldboard width: 3.66 m

Travel speed: 45.5 km/h

Turning radius outside: 7.21 m

Model series: G

Engine manuf.: John Deere

Engine type: PowerTech Plus 6.8L

Engine power: 149 kW

Displacement: 6.8 l

Max. torque: 915 Nm

No. of cylinders: 6

Emission level: Tier 3/EU IIIA

More technical details, like: steering mode, drive, front blade width, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: No

Download datasheets (PDF)

John Deere Construction 620GP FAQ

When was the John Deere Construction 620GP manufactured?

The John Deere Construction 620GP was first produced in 2014.

How much does the John Deere Construction 620GP weigh?

The John Deere Construction 620GP weighs 14.9 tons.

What are the transport dimensions of the John Deere Construction 620GP grader?

The John Deere Construction 620GP grader has a transport length of 8.89 meters, a transport width of 2.49 meters, and a transport height of 3.4 meters.

What is the travel speed of the John Deere Construction 620GP grader?

The John Deere Construction 620GP grader has a travel speed of 45.5 km/h.

What are the undercarriage tyre specifications of the John Deere Construction 620GP grader?

The John Deere Construction 620GP grader is equipped with standard tyres sized 17.5 R25.

What is the outside turning radius of the John Deere Construction 620GP grader?

The John Deere Construction 620GP grader has an outside turning radius of 7.21 meters.

What is the mouldboard width of the John Deere Construction 620GP grader?

The mouldboard width of the John Deere Construction 620GP grader is 3.66 meters.

How much is a John Deere Construction 620GP Grader (2014u20132025) worth?

The residual value of the John Deere Construction 620GP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
