160M3 Caterpillar 160M3 Specifications & Technical Data (2017—2026)

Weight: 20.66t – Standard tyres: 14.0R24 – Transport length: 8.912m – Transport width: 2.511m – Transport height: 3.308m – Mouldboard width: 4.2m

160M3

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 160M3 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 20.66 t

Standard tyres: 14.0R24

Transport length: 8.912 m

Transport width: 2.511 m

Transport height: 3.308 m

Mouldboard width: 4.2 m

Travel speed: 47.4 km/h

Turning radius outside: 7.8 m

Engine manuf.: Caterpillar

Engine type: C9.3 Acert

Engine power: 165 kW

Displacement: 9 l

Max. torque: 1464 Nm

No. of cylinders: 6

Cylinder bore x stroke: 115 x 149 mm

Emission level: Tier 4 f. IV

More technical details, like: steering mode, drive, front blade width, model series, dimension lxwxh, revolutions at max torque are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: Yes

Download specalog and datasheets (PDF)

160M3 Caterpillar Specification for Europe (EN)

Caterpillar 160M3 FAQ

When was the Caterpillar 160M3 manufactured?

The Caterpillar 160M3 was first produced in 2017.

How much does the Caterpillar 160M3 grader weigh?

The Caterpillar 160M3 grader weighs 20.66 tons.

What are the transport dimensions of the Caterpillar 160M3 grader?

The Caterpillar 160M3 grader has a transport length of 8.91 meters, a transport width of 2.51 meters, and a transport height of 3.31 meters.

What is the travel speed of the Caterpillar 160M3 grader?

The Caterpillar 160M3 grader has a travel speed of 47.4 km/h.

What are the standard tyres of the Caterpillar 160M3 grader?

The Caterpillar 160M3 grader is equipped with standard tyres sized 14.0R24.

What is the turning radius of the Caterpillar 160M3 grader?

The Caterpillar 160M3 grader has an outside turning radius of 7.8 meters.

What is the mouldboard width of the Caterpillar 160M3 grader?

The Caterpillar 160M3 grader has a mouldboard width of 4.2 meters.

How much is a Caterpillar 160M3 Grader (2017u20132025) worth?

The residual value of the Caterpillar 160M3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
