140K2 Caterpillar 140K2 Specifications & Technical Data (2017—2026)

Weight: 17.27t – Standard tyres: 14.00-24 12PR (G-2) – Transport length: 8.5m – Transport width: 2.48m – Transport height: 3.35m – Mouldboard width: 3.7m

140K2

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 140K2 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 17.27 t

Standard tyres: 14.00-24 12PR (G-2)

Transport length: 8.5 m

Transport width: 2.48 m

Transport height: 3.35 m

Mouldboard width: 3.7 m

Travel speed: 47.3 km/h

Turning radius outside: 7.5 m

Engine manuf.: Caterpillar

Engine type: C7 Acert

Engine power: 128 kW

Displacement: 7.2 l

Revolutions at max torque: 1000 rpm

Max. torque: 996 Nm

No. of cylinders: 6

Cylinder bore x stroke: 105x127 mm

Emission level: Bharat III / China Nonroad III

More technical details, like: steering mode, drive, front blade width, model series, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: No

Download specalog and datasheets (PDF)

140K2 Caterpillar Specification for Europe (EN)

Caterpillar 140K2 FAQ

When was the Caterpillar 140K2 manufactured?

The Caterpillar 140K2 was first produced in 2017.

How much does the Caterpillar 140K2 grader weigh?

The Caterpillar 140K2 grader weighs 17.27 tons.

What are the transport dimensions of the Caterpillar 140K2 grader?

The Caterpillar 140K2 grader has a transport length of 8.5 meters, a transport width of 2.48 meters, and a transport height of 3.35 meters.

What is the travel speed of the Caterpillar 140K2 grader?

The Caterpillar 140K2 grader has a travel speed of 47.3 km/h.

What are the undercarriage tyre specifications of the Caterpillar 140K2 grader?

The Caterpillar 140K2 grader is equipped with standard tyres sized 14.00-24 12PR (G-2).

What is the turning radius of the Caterpillar 140K2 grader?

The Caterpillar 140K2 grader has an outside turning radius of 7.5 meters.

What is the mouldboard width of the Caterpillar 140K2 grader?

The Caterpillar 140K2 grader has a mouldboard width of 3.7 meters.

How much is a Caterpillar 140K2 Grader (2017u20132025) worth?

The residual value of the Caterpillar 140K2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
