Caterpillar 140 AWD Specifications & Technical Data (2019-2026)

Technical specs - 140 AWD Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 20.24 t

Standard tyres: 14.00R24

Drive: A

Transport length: 10.1 m

Transport width: 2.48 m

Transport height: 3.35 m

Mouldboard width: 3.7 m

Travel speed: 48.4 km/h

Engine manuf.: Caterpillar

Engine type: C9.3

Engine power: 186 kW

Displacement: 9.3 l

Revolutions at max torque: 1550 rpm

Max. torque: 1350 Nm

No. of cylinders: 6

Cylinder bore x stroke: 115x149 mm

Emission level: U.S. EPA Tier 4 Final / EU IV

More technical details, like: steering mode, front blade width, turning radius outside, model series, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: Yes
Aircondition: Yes

Download specalog and datasheets (PDF)

140 AWD Caterpillar Specification for North America (EN)

Caterpillar 140 AWD FAQ

When was the Caterpillar 140 AWD manufactured?

The Caterpillar 140 AWD was first produced in 2019.

How much does the Caterpillar 140 AWD grader weigh?

The Caterpillar 140 AWD grader weighs 20.24 tons.

What are the transport dimensions of the Caterpillar 140 AWD grader?

The Caterpillar 140 AWD grader has a transport length of 10.1 meters, a transport width of 2.48 meters, and a transport height of 3.35 meters.

What is the travel speed of the Caterpillar 140 AWD grader?

The Caterpillar 140 AWD grader has a travel speed of 48.4 km/h.

What are the undercarriage specifications of the Caterpillar 140 AWD grader?

The Caterpillar 140 AWD grader has an all-wheel drive system and uses standard tyres sized 14.00R24.

What is the mouldboard width of the Caterpillar 140 AWD grader?

The Caterpillar 140 AWD grader has a mouldboard width of 3.7 meters.

How much is a Caterpillar 140 AWD Grader (2019u20132025) worth?

The residual value of the Caterpillar 140 AWD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
