120M2 Caterpillar 120M2 Specifications & Technical Data (2017—2019)

Weight: 16.9t – Standard tyres: 17.5R26 – Steering mode: VKL – Drive: A – Transport length: 9.9m – Transport width: 2.5m

120M2

Years of manufacture: 2017—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 120M2 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 16.9 t

Standard tyres: 17.5R26

Steering mode: VKL

Drive: A

Transport length: 9.9 m

Transport width: 2.5 m

Transport height: 3.28 m

Mouldboard width: 3.7 m

Travel speed: 45 km/h

Turning radius outside: 7.76 m

Engine manuf.: Caterpillar

Engine type: C6.6 Acert

Engine power: 114 kW

Displacement: 6.6 l

More technical details, like: front blade width, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: Yes

Download specalog and datasheets (PDF)

120M2 Caterpillar Specification for Europe (EN)

Caterpillar 120M2 FAQ

When was the Caterpillar 120M2 manufactured?

The Caterpillar 120M2 was manufactured from 2017 to 2019.

How much does the Caterpillar 120M2 grader weigh?

The Caterpillar 120M2 grader weighs 16.9 tons.

What are the transport dimensions of the Caterpillar 120M2 grader?

The Caterpillar 120M2 grader has a transport length of 9.9 meters, a transport width of 2.5 meters, and a transport height of 3.28 meters.

What is the travel speed of the Caterpillar 120M2 grader?

The Caterpillar 120M2 grader has a travel speed of 45 km/h.

What are the undercarriage specifications of the Caterpillar 120M2 grader?

The Caterpillar 120M2 grader features an all-wheel drive system and is equipped with standard tyres sized 17.5R26.

What are the maneuverability specifications of the Caterpillar 120M2 grader?

The Caterpillar 120M2 grader has an outside turning radius of 7.76 meters and features front and articulated-frame steering.

What is the mouldboard width of the Caterpillar 120M2 grader?

The Caterpillar 120M2 grader has a mouldboard width of 3.7 meters.

How much is a Caterpillar 120M2 Grader (2017u20132019) worth?

The residual value of the Caterpillar 120M2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
