Technical specs - 120M AWD Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 18.4 t

Standard tyres: 14.00R24

Steering mode: VKL

Drive: A

Transport length: 8.488 m

Transport width: 2.549 m

Transport height: 3.308 m

Mouldboard width: 3.7 m

Travel speed: 47.5 km/h

Turning radius outside: 7.3 m

Engine manuf.: Caterpillar

Engine type: C6.6 Acert VHP

Engine power: 136 kW

Displacement: 6.6 l

Revolutions at max torque: 1400 rpm

Max. torque: 906 Nm

No. of cylinders: 6

Cylinder bore x stroke: 105x127 mm

Emission level: U.S. EPA Tier 3 / EU IIIA

More technical details, like: front blade width, model series, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: Yes

Download specalog and datasheets (PDF)

Caterpillar 120M AWD FAQ

When was the Caterpillar 120M AWD manufactured?

The Caterpillar 120M AWD was manufactured from 2017 to 2019.

How much does the Caterpillar 120M AWD grader weigh?

The Caterpillar 120M AWD grader weighs 18.4 tons.

What are the transport dimensions of the Caterpillar 120M AWD grader?

The Caterpillar 120M AWD grader has a transport length of 8.49 meters, a width of 2.55 meters, and a height of 3.31 meters.

What is the travel speed of the Caterpillar 120M AWD grader?

The Caterpillar 120M AWD grader has a travel speed of 47.5 km/h.

What are the undercarriage specifications of the Caterpillar 120M AWD grader?

The Caterpillar 120M AWD grader has an all-wheel drive system and uses standard tyres sized 14.00R24.

What are the maneuverability specifications of the Caterpillar 120M AWD grader?

The Caterpillar 120M AWD grader has an outside turning radius of 7.3 meters and features front and articulated-frame steering.

What is the mouldboard width of the Caterpillar 120M AWD grader?

The Caterpillar 120M AWD grader has a mouldboard width of 3.7 meters.

How much is a Caterpillar 120M AWD Grader (2017u20132019) worth?

The residual value of the Caterpillar 120M AWD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
