120 Caterpillar 120 Specifications & Technical Data (2019—2026)

Weight: 15.91t – Standard tyres: 14.00R24 – Transport length: 9.84m – Transport width: 2.59m – Transport height: 3.83m – Mouldboard width: 3.7m

120

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 120 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15.91 t

Standard tyres: 14.00R24

Transport length: 9.84 m

Transport width: 2.59 m

Transport height: 3.83 m

Mouldboard width: 3.7 m

Travel speed: 48.3 km/h

Turning radius outside: 7.4 m

Engine manuf.: Caterpillar

Engine type: C7.1

Engine power: 104 kW

Displacement: 7.01 l

Max. torque: 822 Nm

No. of cylinders: 6

Cylinder bore x stroke: 105x135 mm

Emission level: U.S. EPA Tier 4 Final / EU IV

More technical details, like: steering mode, drive, front blade width, model series, dimension lxwxh, revolutions at max torque are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar 120 FAQ

When was the Caterpillar 120 manufactured?

The Caterpillar 120 was first produced in 2019.

How much does the Caterpillar 120 grader weigh?

The Caterpillar 120 grader weighs 15.91 tons.

What are the transport dimensions of the Caterpillar 120 grader?

The Caterpillar 120 grader has a transport length of 9.84 meters, a transport width of 2.59 meters, and a transport height of 3.83 meters.

What is the travel speed of the Caterpillar 120 grader?

The Caterpillar 120 grader has a travel speed of 48.3 km/h.

What are the undercarriage tyre specifications of the Caterpillar 120 grader?

The Caterpillar 120 grader is equipped with standard tyres sized 14.00R24.

What is the turning radius of the Caterpillar 120 grader?

The Caterpillar 120 grader has an outside turning radius of 7.4 meters.

What is the mouldboard width of the Caterpillar 120 grader?

The Caterpillar 120 grader has a mouldboard width of 3.7 meters.

How much is a Caterpillar 120 Grader (2019u20132025) worth?

The residual value of the Caterpillar 120 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
