856D AWD Case 856D AWD Specifications & Technical Data (2024—2026)
Technical specs - 856D AWD Case
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 16.7 t
- Standard tyres
- 17.5 25 EM
- Steering mode
- VKL
- Drive
- A
- Transport length
- 8.6 m
- Transport width
- 2.549 m
- Transport height
- 3.674 m
- Mouldboard width
- 3.7 m
- Front blade width
- 2.45 m
- Travel speed
- 38 km/h
- Turning radius outside
- 8 m
- Model series
- D
- Engine manuf.
- FPT
- Engine type
- 667 TA
- Engine power
- 142 kW
- Displacement
- 6.7 l
- Revolutions at max torque
- 1400 rpm
- Max. torque
- 850 Nm
- No. of cylinders
- 6
- Emission level
- V
More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and central blade
Special equipment
- Diesel particulate filter
-
Yes
- Bilateral levelling automatic
-
No
- Front blade
-
Yes
- Rear ripper
-
Yes
- Aircondition
-
Yes
