836C AWD Case 836C AWD Specifications & Technical Data (2021—2023)

Weight: 12.8t – Standard tyres: 405/70 R 20 – Steering mode: VKL – Drive: A – Transport length: 7.7m – Transport width: 2.35m

836C AWD

Years of manufacture: 2021—2023

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 836C AWD Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 12.8 t

Standard tyres: 405/70 R 20

Steering mode: VKL

Drive: A

Transport length: 7.7 m

Transport width: 2.35 m

Transport height: 3.586 m

Mouldboard width: 3.4 m

Front blade width: 2.35 m

Travel speed: 40 km/h

Turning radius outside: 7.6 m

Model series: C

Engine manuf.: FPT

Engine type: 667 TA

Engine power: 115 kW

Displacement: 6.7 l

Revolutions at max torque: 1400 rpm

Max. torque: 725 Nm

No. of cylinders: 6

Emission level: V

More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: Yes
Bilateral levelling automatic: No
Front blade: Yes
Rear ripper: Yes
Aircondition: Yes

Download datasheets (PDF)

Case 836C AWD FAQ

When was the Case 836C AWD manufactured?

The Case 836C AWD was manufactured from 2021 to 2023.

How much does the Case 836C AWD grader weigh?

The Case 836C AWD grader weighs 12.8 tons.

What are the transport dimensions of the Case 836C AWD grader?

The Case 836C AWD grader has a transport length of 7.7 meters, a transport width of 2.35 meters, and a transport height of 3.59 meters.

What is the travel speed of the Case 836C AWD grader?

The Case 836C AWD grader has a travel speed of 40 km/h.

What is the fuel consumption range of the Case 836C AWD grader?

The fuel consumption range of the Case 836C AWD grader is between 8 and 20 liters per hour.

What are the undercarriage specifications of the Case 836C AWD grader?

The Case 836C AWD grader has an all-wheel drive system and uses standard tyres sized 405/70 R 20.

What are the maneuverability specifications of the Case 836C AWD grader?

The Case 836C AWD grader has an outside turning radius of 7.6 meters and features front and articulated-frame steering.

What are the primary blade specifications of the Case 836C AWD grader?

The Case 836C AWD grader has a front blade width of 2.35 meters and a mouldboard width of 3.4 meters.
