973 C Caterpillar 973 C Specifications & Technical Data (2000—2005)

Model rating
6,00 / 10

Weight: 27.5t – Transport length: 7.078m – Transport width: 2.854m – Transport height: 3.45m – Bucket width: 2.854m – Bucket capacity: 2.8m³

Crawler Loaders Caterpillar 973 C
Crawler Loaders Caterpillar 973 C
Crawler Loaders Caterpillar 973 C
Crawler Loaders Caterpillar 973 C

Technical specs - 973 C Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
27.5 t
Transport length
7.078 m
Transport width
2.854 m
Transport height
3.45 m
Bucket width
2.854 m
Bucket capacity
2.8 m³
Track width
600 mm
Travel speed
9 km/h
Max. discharge height
3.34 m
Engine manuf.
Caterpillar
Engine type
3306 DITA
Engine power
157 kW
Displacement
10.45 l
Revolutions at max torque
2200 rpm

More technical details, like: soil pressure, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, engine model, aspiration, rated speed, engine output - net...

More technical details, like: soil pressure, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, engine model, aspiration, rated speed, engine output - net, transmission type, transmission manufacturer, ranges fwd / rev, carrier rollers per side - std, track rollers per side - std, track shoe width, standard shoe type, track shoes per side - std, overall length, max. height, width no bucket - std, track length on ground, ground clearance, track gauge - standard, shovel 1 width, ripper type 1, max. penetration - ripper 1, shovel 1 dump height 45° max, shovel 1 dump reach 45° max., digging depth, fuel tank capacity, shovel 1 type, shovel 1 capacity, cycle time - raise, ground bearing pressure - standard, static tipping load shovel 1, breakout force - std, std breakout force, operating weight std are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Rear ripper
No
Aircondition
Yes
