Komatsu D37EXi-24 Specifications & Technical Data (2017-2021)

Technical specs - D37EXi-24 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 9.08 t

Transport length: 4.275 m

Transport width: 2.48 m

Transport height: 2.945 m

Blade type: PAT

Track width: 400 mm

Travel speed: 8.5 km/h

Front blade width: 2.71 m

Model series: D

Engine manuf.: Komatsu

Engine type: SAA4D95LE-7

Engine power: 66.1 kW

Displacement: 3.26 l

Revolutions at max torque: 2200 rpm

No. of cylinders: 4

Cylinder bore x stroke: 95x115 mm

Emission level: IV

More technical details, like: soil pressure, reverse travel speed, transmission type, max. drawbar pull, dimension lxwxh, max. torque, undercarriage type, undercarriage system, traction control system, cab - type, rops, fops...

More technical details, like: soil pressure, reverse travel speed, transmission type, max. drawbar pull, dimension lxwxh, max. torque, undercarriage type, undercarriage system, traction control system, cab - type, rops, fops, rear view system available, platform, telematics available, platform, grade control available, platform, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, engine output - gross, transmission type, speed mode - 1, speed mode - 2, carrier rollers, track rollers, raised sprocket, shoe - width, shoe - type, ground contact area, number of shoes, height - max, height - top of rops, ground clearance, width - over tracks, track length - on ground, blade, blade - width, blade - height, blade - dig depth, blade - lift clearance, blade - tilt, fuel tank, blade - capacity, speed - forward maximum, speed - reverse maximum, ground bearing pressure, implement pump - flow, implement pump - pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and corresponding blade

Special equipment

Diesel particulate filter: No
Rear ripper: No
Tilt device: No
Aircondition: No

Download datasheets (PDF)

Komatsu D37EXi-24 FAQ

When was the Komatsu D37EXi-24 manufactured?

The Komatsu D37EXi-24 was manufactured from 2017 to 2021.

How much does the Komatsu D37EXi-24 weigh?

The Komatsu D37EXi-24 weighs 9.08 tons.

What are the transport dimensions of the Komatsu D37EXi-24 bulldozer?

The Komatsu D37EXi-24 has a transport length of 4.28 meters, a transport width of 2.48 meters, and a transport height of 2.95 meters.

What is the travel speed of the Komatsu D37EXi-24 bulldozer?

The Komatsu D37EXi-24 bulldozer has a travel speed of 8.5 km/h.

What is the track width of the Komatsu D37EXi-24's undercarriage?

The Komatsu D37EXi-24 has a track width of 400 mm.

What are the specifications of the primary work tool on the Komatsu D37EXi-24?

The Komatsu D37EXi-24 is equipped with a 6-way blade that has a front blade width of 2.71 meters.

How much is a Komatsu D37EXi-24 Bulldozer (2017u20132021) worth?

The residual value of the Komatsu D37EXi-24 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
