950K LGP John Deere Construction 950K LGP Specifications & Technical Data (2017—2026)
Technical specs - 950K LGP John Deere Construction
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 31.43 t
- Transport length
- 6.64 m
- Transport width
- 4.57 m
- Transport height
- 3.43 m
- Blade type
- S
- Soil pressure
- 0.75 kg/cm²
- Track width
- 910 mm
- Travel speed
- 11 km/h
- Reverse travel speed
- 11 km/h
- Front blade width
- 3.91 m
- Transmission type
- HY
- max. Drawbar Pull
- 55.78 t
- Model series
- K
- Engine manuf.
- John Deere
- Engine type
- PowerTech PSS 6090
- Engine power
- 198 kW
- Displacement
- 9 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 1245/1300 Nm
- No. of cylinders
- 6
- Emission level
- Tier 4f/EU IV
More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and corresponding blade
Special equipment
- Diesel particulate filter
-
No
- Rear ripper
-
No
- Tilt device
-
No
- Aircondition
-
Yes
