8.23 F Venieri 8.23 F Specifications & Technical Data (2016—2019)

The Venieri 8.23 F is a backhoe loader manufactured by Venieri since 2016. It has a weight of 8.49 tons and a transport length of …

The Venieri 8.23 F is a backhoe loader manufactured by Venieri since 2016. It has a weight of 8.49 tons and a transport length of 5.9 meters. The bucket capacity is 1.4 cubic meters, with a tear-out force of 69 kilonewtons. It can dredge up to a depth of 4.6 meters and has a bucket width of 2.2 meters. The maximum discharge height is 3.4 meters, and it has a maximum reach horizontal of 8 meters. The backhoe loader has a transport width of 2.2 meters and a transport height of 3.5 meters. Additionally, it is equipped with special equipment including air conditioning, a clamshell, forklift utility, grabber, and outrigger stabilizers.

8.23 F

Years of manufacture: 2016—2019

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 8.23 F Venieri

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.49 t

Standard tyres: 405/70-24

Bucket width: 2.2 m

Bucket capacity: 1.4 m³

Drive: A

Transport length: 5.9 m

Transport width: 2.2 m

Transport height: 3.5 m

Tear-out force: 69 kN

Max. Reach horizontal: 8 m

Dredging depth: 4.6 m

Max. discharge height: 3.4 m

Engine manuf.: Deutz

Engine type: TCD3.6 L4

Engine power: 78 kW

Displacement: 3.6 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 4

Emission level: IIIb

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, model series, dimension lxwxh, max. torque, cylinder bore x stroke, backhoe type, engine manufacturer, engine model, aspiration, rated speed, engine output - net, engine output - gross, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, ground clearance, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, reach from slew pivot - non-extending dipper, loading height - non-extending dipper, dump height - general purpose, dump angle - general purpose, fuel tank, shovel capacity - standard general purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: Yes
Forklift utility: Yes
Grabber: Yes
Diesel particulate filter: No
Aircondition: Yes

Venieri 8.23 F FAQ

When was the Venieri 8.23 F manufactured?

The Venieri 8.23 F was first produced in 2016.

How much does the Venieri 8.23 F backhoe loader weigh?

The Venieri 8.23 F backhoe loader weighs 8.49 tons.

What are the transport dimensions of the Venieri 8.23 F backhoe loader?

The Venieri 8.23 F has a transport length of 5.9 meters, a transport width of 2.2 meters, and a transport height of 3.5 meters.

What are the undercarriage specifications of the Venieri 8.23 F backhoe loader?

The Venieri 8.23 F backhoe loader has an all-wheel drive system and uses standard tyres sized 405/70-24.

What are the dredging depth and maximum horizontal reach of the Venieri 8.23 F backhoe loader?

The Venieri 8.23 F backhoe loader has a dredging depth of 4.6 meters and a maximum horizontal reach of 8 meters.

What is the tear-out force of the Venieri 8.23 F backhoe loader?

The Venieri 8.23 F backhoe loader has a tear-out force of 69 kN.

What is the maximum discharge height of the Venieri 8.23 F?

The Venieri 8.23 F has a maximum discharge height of 3.4 meters.

What are the specifications of the primary work tool on the Venieri 8.23 F backhoe loader?

The primary work tool of the Venieri 8.23 F has a bucket capacity of 1.4 cubic meters and a bucket width of 2.2 meters.
