8.23 E Venieri 8.23 E Specifications & Technical Data (2013—2016)

The Venieri 8.23 E is a backhoe loader manufactured by Venieri from 2013 to 2016. It has a weight of 9 tons and a transport length…

The Venieri 8.23 E is a backhoe loader manufactured by Venieri from 2013 to 2016. It has a weight of 9 tons and a transport length of 5.9 meters. The bucket capacity is 1.4 cubic meters, with a tear-out force of 45 kilonewtons. It can dredge up to a depth of 4.5 meters and has a bucket width of 2.2 meters. The maximum discharge height is 3.2 meters, and it has a maximum reach horizontal of 5.78 meters. The backhoe loader has a transport width of 2.2 meters and a transport height of 3.5 meters. It is equipped with special equipment including a clamshell, forklift utility, and outrigger stabilizers.

8.23 E

Years of manufacture: 2013—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 8.23 E Venieri

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 9 t

Standard tyres: 405/70-24

Bucket width: 2.2 m

Bucket capacity: 1.4 m³

Drive: A

Transport length: 5.9 m

Transport width: 2.2 m

Transport height: 3.5 m

Tear-out force: 45 kN

Max. Reach horizontal: 5.78 m

Dredging depth: 4.5 m

Max. discharge height: 3.2 m

Engine manuf.: Perkins

Engine type: 1104D-44T

Engine power: 75 kW

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: Yes
Forklift utility: Yes
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Venieri 8.23 E FAQ

When was the Venieri 8.23 E manufactured?

The Venieri 8.23 E was manufactured from 2013 to 2016.

How much does the Venieri 8.23 E backhoe loader weigh?

The Venieri 8.23 E backhoe loader weighs 9 tons.

What are the transport dimensions of the Venieri 8.23 E backhoe loader?

The Venieri 8.23 E has a transport length of 5.9 meters, a transport width of 2.2 meters, and a transport height of 3.5 meters.

What are the undercarriage specifications of the Venieri 8.23 E backhoe loader?

The Venieri 8.23 E backhoe loader has an all-wheel drive system and uses standard tyres sized 405/70-24.

What are the excavation capabilities of the Venieri 8.23 E backhoe loader?

The Venieri 8.23 E backhoe loader has a dredging depth of 4.5 meters and a maximum horizontal reach of 5.78 meters.

What is the tear-out force of the Venieri 8.23 E backhoe loader?

The Venieri 8.23 E backhoe loader has a tear-out force of 45 kN.

What is the maximum discharge height of the Venieri 8.23 E?

The Venieri 8.23 E has a maximum discharge height of 3.2 meters.

What are the specifications of the primary work tool bucket on the Venieri 8.23 E backhoe loader?

The primary work tool bucket of the Venieri 8.23 E has a capacity of 1.4 cubic meters and a width of 2.2 meters.

How much is a Venieri 8.23 E Backhoe loader (2013u20132016) worth?

The residual value of the Venieri 8.23 E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
