PB 130 Palazzani PB 130 Specifications & Technical Data (2013—2020)

The Palazzani PB 130 is a backhoe loader manufactured by Palazzani from 2013 to 2020. It has a weight of 3.8 tons and a transport …

The Palazzani PB 130 is a backhoe loader manufactured by Palazzani from 2013 to 2020. It has a weight of 3.8 tons and a transport length of 4.8 meters. The bucket capacity is 0.5 cubic meters, with a tear-out force of 36.5 kilonewtons. It can dredge up to a depth of 2.8 meters and has a bucket width of 1.49 meters. The maximum discharge height is 1.9 meters, and it has a maximum reach horizontal of 3.55 meters. The backhoe loader has a transport width and height of 1.49 meters and 2.41 meters respectively. It is equipped with special equipment including a clamshell and outrigger stabilizers. The backhoe bucket capacity is 0.045 cubic meters.

PB 130

Years of manufacture: 2013—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PB 130 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.8 t

Standard tyres: 10x16.5

Bucket width: 1.49 m

Bucket capacity: 0.5 m³

Bucket capacity backhoe: 0.045 m³

Drive: A

Transport length: 4.8 m

Transport width: 1.49 m

Transport height: 2.41 m

Tear-out force: 36.5 kN

Max. Reach horizontal: 3.55 m

Dredging depth: 2.8 m

Max. discharge height: 1.9 m

Model series: PB

Engine manuf.: Yanmar

Engine type: 4TNV88

Engine power: 32.5 kW

Displacement: 2.2 l

Revolutions at max torque: 2600 rpm

No. of cylinders: 4

Emission level: Tier 4 f

More technical details, like: tear-out force backhoe, travel speed, dimension lxwxh, max. torque, cylinder bore x stroke, backhoe type, engine manufacturer, engine model, aspiration, rated speed, engine output - gross, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, ground clearance, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, reach from slew pivot - non-extending dipper, loading height - non-extending dipper, dump height - general purpose, fuel tank, shovel capacity - standard general purpose, shovel breakout - general purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: Yes
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Palazzani PB 130 FAQ

When was the Palazzani PB 130 manufactured?

The Palazzani PB 130 was manufactured from 2013 to 2020.

How much does the Palazzani PB 130 weigh?

The Palazzani PB 130 weighs 3.8 tons.

What are the transport dimensions of the Palazzani PB 130 backhoe loader?

The Palazzani PB 130 has a transport length of 4.8 meters, a transport width of 1.49 meters, and a transport height of 2.41 meters.

What are the undercarriage specifications of the Palazzani PB 130 backhoe loader?

The Palazzani PB 130 backhoe loader has an all-wheel drive system and is equipped with standard tyres sized 10x16.5.

What are the excavation performance specifications of the Palazzani PB 130 backhoe loader?

The Palazzani PB 130 has a dredging depth of 2.8 meters and a maximum horizontal reach of 3.55 meters.

What is the tear-out force of the Palazzani PB 130 backhoe loader?

The Palazzani PB 130 backhoe loader has a tear-out force of 36.5 kN.

What is the maximum discharge height of the Palazzani PB 130?

The Palazzani PB 130 has a maximum discharge height of 1.9 meters.

What are the primary work tool specifications of the Palazzani PB 130 backhoe loader?

The Palazzani PB 130 has a bucket capacity of 0.5 cubic meters, a bucket width of 1.49 meters, and a backhoe bucket capacity of 0.05 cubic meters.
