B11B New Holland B11B Specifications & Technical Data (2008—2012)

The New Holland B11B Backhoe Loader, manufactured from 2008 to 2012, is a construction machine with a weight of 8.5 tons. It has a…

The New Holland B11B Backhoe Loader, manufactured from 2008 to 2012, is a construction machine with a weight of 8.5 tons. It has a transport length of 5.69 meters and a bucket capacity of 1 cubic meter. The tear-out force is 6.296 kilonewtons, and it can dredge up to a depth of 4.595 meters. The bucket width is 2.25 meters, and it can reach a maximum discharge height of 3.84 meters. The maximum reach horizontally is 3.54 meters. The transport width is 2.275 meters, and the transport height is 3.96 meters.

Backhoe Loaders New Holland B11B

Technical specs - B11B New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.5 t
Standard tyres
12.5/80-18
Bucket width
2.25 m
Bucket capacity
1 m³
Drive
A
Transport length
5.69 m
Transport width
2.275 m
Transport height
3.96 m
Tear-out force
6.296 kN
Max. Reach horizontal
3.54 m
Dredging depth
4.595 m
Max. discharge height
3.84 m
Model series
B
Engine manuf.
CNH
Engine type
F4GE0484G*D
Engine power
82 kW
Displacement
4.5 l
Revolutions at max torque
1400 rpm

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, backhoe type, telematics available, engine manufacturer, engine model...

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, backhoe type, telematics available, engine manufacturer, engine model, emission rating, aspiration, charged air cooling, rated speed, engine output - net, engine output - gross, torque rated speed, torque, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, ground clearance, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - general purpose, dump angle - general purpose, dump height - multi-purpose, dump angle - multi-purpose, fuel tank, shovel capacity - standard general purpose, shovel capacity - multi-purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, shovel breakout - multi-purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

New Holland B11B FAQ

When was the New Holland B11B manufactured?

The New Holland B11B was manufactured from 2008 to 2012.

How much does the New Holland B11B backhoe loader weigh?

The New Holland B11B backhoe loader weighs 8.5 tons.

What are the transport dimensions of the New Holland B11B backhoe loader?

The New Holland B11B has a transport length of 5.69 meters, a transport width of 2.28 meters, and a transport height of 3.96 meters.

What are the undercarriage specifications of the New Holland B11B backhoe loader?

The New Holland B11B backhoe loader has an all-wheel drive system and is equipped with standard tyres sized 12.5/80-18.

What are the excavation performance specifications of the New Holland B11B backhoe loader?

The New Holland B11B has a dredging depth of 4.595 meters and a maximum horizontal reach of 3.54 meters.

What is the tear-out force of the New Holland B11B backhoe loader?

The New Holland B11B backhoe loader has a tear-out force of 6.296 kN.

What is the material handling capacity of the New Holland B11B in terms of maximum discharge height?

The New Holland B11B has a maximum discharge height of 3.84 meters.

What are the specifications of the primary work tool on the New Holland B11B backhoe loader?

The primary work tool of the New Holland B11B backhoe loader has a bucket capacity of 1 cubic meter and a bucket width of 2.25 meters.
