B110C TC New Holland B110C TC Specifications & Technical Data (2016—2021)

The New Holland B110C TC is a backhoe loader manufactured by New Holland from 2016 to 2021. It has a weight of 8.8 tons and a tran…

The New Holland B110C TC is a backhoe loader manufactured by New Holland from 2016 to 2021. It has a weight of 8.8 tons and a transport length of 5.69 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 59 kilonewtons. It can dredge up to a depth of 5.76 meters and has a bucket width of 2.25 meters. The maximum discharge height is 4.5 meters, and it has a maximum reach horizontal of 6.5 meters. The transport width is 2.275 meters, and the transport height is 3.96 meters. Special equipment includes air conditioning, clamshell, forklift utility, and outrigger stabilizers.

B110C TC

Years of manufacture: 2016—2021

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - B110C TC New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.8 t

Standard tyres: 480/80R26 HA

Bucket width: 2.25 m

Bucket capacity: 1 m³

Drive: A

Transport length: 5.69 m

Transport width: 2.275 m

Transport height: 3.96 m

Tear-out force: 59 kN

Max. Reach horizontal: 6.5 m

Dredging depth: 5.76 m

Max. discharge height: 4.5 m

Model series: B

Engine manuf.: CNH

Engine type: F5H-HI-eSCR

Engine power: 82 kW

Displacement: 3.4 l

Emission level: Tier 4 B

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: Yes
Forklift utility: Yes
Grabber: No
Diesel particulate filter: No
Aircondition: Yes

New Holland B110C TC FAQ

When was the New Holland B110C TC manufactured?

The New Holland B110C TC was manufactured from 2016 to 2021.

How much does the New Holland B110C TC weigh?

The New Holland B110C TC weighs 8.8 tons.

What are the transport dimensions of the New Holland B110C TC backhoe loader?

The New Holland B110C TC has a transport length of 5.69 meters, a transport width of 2.28 meters, and a transport height of 3.96 meters.

What are the undercarriage specifications of the New Holland B110C TC backhoe loader?

The New Holland B110C TC features an all-wheel drive system and standard tyres sized 480/80R26 HA.

What are the dredging depth and maximum horizontal reach of the New Holland B110C TC backhoe loader?

The New Holland B110C TC has a dredging depth of 5.76 meters and a maximum horizontal reach of 6.5 meters.

What is the tear-out force of the New Holland B110C TC backhoe loader, given that no power ratings are provided?

The New Holland B110C TC backhoe loader has a tear-out force of 59 kN. No power ratings are provided in the available data.

What is the maximum discharge height of the New Holland B110C TC backhoe loader?

The New Holland B110C TC has a maximum discharge height of 4.5 meters.

What are the specifications of the bucket on the New Holland B110C TC backhoe loader?

The bucket of the New Holland B110C TC has a capacity of 1 cubic meter and a width of 2.25 meters.
