B110C TC New Holland B110C TC Specifications & Technical Data (2012—2015)

The New Holland B110C TC is a backhoe loader manufactured from 2012 to 2015. It has a weight of 8.5 tons and a transport length of…

The New Holland B110C TC is a backhoe loader manufactured from 2012 to 2015. It has a weight of 8.5 tons and a transport length of 5.69 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 6.296 kilonewtons. It can dredge up to a depth of 4.595 meters and has a bucket width of 2.25 meters. The maximum discharge height is 3.84 meters, and it can reach a maximum horizontal distance of 3.54 meters. The transport width is 2.275 meters, and the transport height is 3.96 meters.

B110C TC

Years of manufacture: 2012—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - B110C TC New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.5 t

Standard tyres: 12.5/80-18

Bucket width: 2.25 m

Bucket capacity: 1 m³

Drive: A

Transport length: 5.69 m

Transport width: 2.275 m

Transport height: 3.96 m

Tear-out force: 6.296 kN

Max. Reach horizontal: 3.54 m

Dredging depth: 4.595 m

Max. discharge height: 3.84 m

Model series: B

Engine manuf.: CNH

Engine type: 455TA-EGH

Engine power: 82 kW

Displacement: 4.5 l

Revolutions at max torque: 2200 rpm

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, backhoe type, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, engine output - gross, torque rated speed, torque, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, dig depth - sae retracted dipper, dig depth - sae extended dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - multi-purpose, dump angle - multi-purpose, turning radius kerb - 4wd not braked, fuel tank, shovel capacity - multi-purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - multi-purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

New Holland B110C TC FAQ

When was the New Holland B110C TC manufactured?

The New Holland B110C TC was manufactured from 2012 to 2015.

How much does the New Holland B110C TC weigh?

The New Holland B110C TC weighs 8.5 tons.

What are the transport dimensions of the New Holland B110C TC backhoe loader?

The New Holland B110C TC has a transport length of 5.69 meters, a transport width of 2.28 meters, and a transport height of 3.96 meters.

What are the undercarriage specifications of the New Holland B110C TC backhoe loader?

The New Holland B110C TC backhoe loader has an all-wheel drive system and is equipped with standard tyres sized 12.5/80-18.

What are the excavation performance specifications of the New Holland B110C TC backhoe loader?

The New Holland B110C TC has a dredging depth of 4.595 meters and a maximum horizontal reach of 3.54 meters.

What is the tear-out force of the New Holland B110C TC backhoe loader?

The New Holland B110C TC backhoe loader has a tear-out force of 6.296 kN.

What is the maximum discharge height of the New Holland B110C TC?

The New Holland B110C TC has a maximum discharge height of 3.84 meters.

What are the specifications of the primary work tool bucket on the New Holland B110C TC?

The primary work tool bucket of the New Holland B110C TC has a capacity of 1 cubic meter and a width of 2.25 meters.

How much is a New Holland B110C TC Backhoe loader (2012u20132015) worth?

The residual value of the New Holland B110C TC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
