B110C New Holland B110C Specifications & Technical Data (2021—2026)

The New Holland B110C is a backhoe loader manufactured since 2021. It has a weight of 8.403 tons and a transport length of 7.03 me…

The New Holland B110C is a backhoe loader manufactured since 2021. It has a weight of 8.403 tons and a transport length of 7.03 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 63.4 kN. The dredging depth is 4.727 meters, and the bucket width is 2.25 meters. The maximum reach horizontal is 5.853 meters. The transport width is 2.3 meters, and the transport height is 3.815 meters. The backhoe has a bucket capacity of 0.24 cubic meters and a tear-out force of 58.83 kN. It also comes equipped with a clamshell.

B110C

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - B110C New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.4 t

Standard tyres: 12-16.5/19.5L-24

Bucket width: 2.25 m

Bucket capacity: 1 m³

Bucket capacity backhoe: 0.24 m³

Drive: A

Transport length: 7.03 m

Transport width: 2.3 m

Transport height: 3.82 m

Tear-out force: 63.4 kN

Tear-out force backhoe: 58.83 kN

Max. Reach horizontal: 5.853 m

Dredging depth: 4.727 m

Model series: B

Engine manuf.: FPT

Engine type: F5BFL413A*B006

Engine power: 82 kW

Revolutions at max torque: 1400 rpm

Max. torque: 466 Nm

Emission level: Tier 4F

More technical details, like: max. discharge height, travel speed, dimension lxwxh, displacement, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: Yes
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

B110C New Holland Specification for North America (EN)

New Holland B110C FAQ

When was the New Holland B110C manufactured?

The New Holland B110C was first produced in 2021.

How much does the New Holland B110C backhoe loader weigh?

The New Holland B110C backhoe loader weighs 8.4 tons.

What are the transport dimensions of the New Holland B110C backhoe loader?

The New Holland B110C has a transport length of 7.03 meters, a transport width of 2.3 meters, and a transport height of 3.82 meters.

What are the undercarriage specifications of the New Holland B110C backhoe loader?

The New Holland B110C backhoe loader features an all-wheel drive system and comes with standard tyres sized 12-16.5/19.5L-24.

What are the dredging depth and maximum horizontal reach of the New Holland B110C backhoe loader?

The New Holland B110C has a dredging depth of 4.727 meters and a maximum horizontal reach of 5.853 meters.

What are the tear-out forces of the New Holland B110C backhoe loader?

The New Holland B110C has a tear-out force of 63.4 kN and a backhoe tear-out force of 58.83 kN.

What are the specifications of the primary work tools on the New Holland B110C backhoe loader?

The New Holland B110C features a front loader bucket with a capacity of 1 cubic meter and a width of 2.25 meters, and a backhoe bucket with a capacity of 0.24 cubic meters.
