9250 A John Deere Construction 9250 A Specifications & Technical Data (1982—2021)

The John Deere Construction 9250 A Backhoe Loader, manufactured from 1982 to 2021, weighs 1.157 tons. It has a bucket capacity of …

The John Deere Construction 9250 A Backhoe Loader, manufactured from 1982 to 2021, weighs 1.157 tons. It has a bucket capacity of 0.76 cubic meters and a dredging depth of 4.17 meters. The bucket width is 2.03 meters, and it can reach a maximum discharge height of 3.43 meters. With a maximum horizontal reach of 5.31 meters, it has a transport height of 3.4 meters. Additionally, it has a backhoe bucket capacity of 0.045 cubic meters.

Backhoe Loaders John Deere Construction 9250 A

Technical specs - 9250 A John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.157 t
Standard tyres
F: 14.9-24 6ply R: 11L-15 8-ply F3
Bucket width
2.03 m
Bucket capacity
0.76 m³
Bucket capacity backhoe
0.045 m³
Transport height
3.4 m
Max. Reach horizontal
5.31 m
Dredging depth
4.17 m
Max. discharge height
3.43 m
Model series
A
Engine manuf.
Kohler
Engine type
KDI2504
Engine power
48 kW
Max. torque
305/1500 Nm
No. of cylinders
4

More technical details, like: drive, transport length, transport width, tear-out force, tear-out force backhoe, travel speed, dimension lxwxh, displacement, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

John Deere Construction 9250 A FAQ

When was the John Deere Construction 9250 A manufactured?

The John Deere Construction 9250 A was manufactured from 1982 to 2021.

How much does the John Deere Construction 9250 A weigh?

The John Deere Construction 9250 A weighs 1.16 tons.

What is the transport height of the John Deere Construction 9250 A backhoe loader?

The transport height of the John Deere Construction 9250 A backhoe loader is 3.4 meters.

What are the undercarriage tyre specifications of the John Deere Construction 9250 A backhoe loader?

The John Deere Construction 9250 A is equipped with front tyres sized 14.9-24 6-ply and rear tyres sized 11L-15 8-ply F3 as standard.

What are the excavation specifications of the John Deere Construction 9250 A backhoe loader?

The John Deere Construction 9250 A has a dredging depth of 4.17 meters and a maximum horizontal reach of 5.31 meters.

What is the maximum discharge height of the John Deere Construction 9250 A?

The John Deere Construction 9250 A has a maximum discharge height of 3.43 meters.

What are the specifications of the primary work tool on the John Deere Construction 9250 A backhoe loader?

The John Deere Construction 9250 A has a bucket capacity of 0.76 cubic meters, a bucket width of 2.03 meters, and a backhoe bucket capacity of 0.05 cubic meters.
