710 J John Deere Construction 710 J Specifications & Technical Data (2007—2012)

The John Deere Construction 710 J is a backhoe loader manufactured by John Deere Construction from 2007 to 2012. It has a weight o…

The John Deere Construction 710 J is a backhoe loader manufactured by John Deere Construction from 2007 to 2012. It has a weight of 10.454 tons and a transport length of 8.15 meters. The bucket capacity is 1.24 cubic meters, with a tear-out force of 69.1 kilonewtons. The dredging depth is 6.81 meters, and the bucket width is 2.464 meters. The maximum discharge height is 5.18 meters, and the maximum reach horizontal is 9.46 meters. It has a travel speed of 39.6 kilometers per hour. The transport width is 2.29 meters, and the transport height is 2.97 meters. The backhoe has a bucket capacity of 0.31 cubic meters and a tear-out force of 75.6 kilonewtons. It also includes special equipment such as a diesel particulate filter, forklift utility, and outrigger stabilizers.

710 J

Years of manufacture: 2007—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 710 J John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.454 t

Standard tyres: F: 14.5/75-16.1 SL F-3 R: 21L-28 R-4

Bucket width: 2.464 m

Bucket capacity: 1.24 m³

Bucket capacity backhoe: 0.31 m³

Transport length: 8.15 m

Transport width: 2.29 m

Transport height: 2.97 m

Tear-out force: 69.1 kN

Tear-out force backhoe: 75.6 kN

Max. Reach horizontal: 9.46 m

Dredging depth: 6.81 m

Max. discharge height: 5.18 m

Travel speed: 39.6 km/h

Model series: J

Engine manuf.: John Deere

Engine type: 6068T

Engine power: 92 kW

Displacement: 6.8 l

Max. torque: 537 Nm

No. of cylinders: 6

Emission level: EPA Tier 2

More technical details, like: drive, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: No
Forklift utility: Yes
Grabber: No
Diesel particulate filter: Yes
Aircondition: No

Download datasheets (PDF)

John Deere Construction 710 J FAQ

When was the John Deere Construction 710 J manufactured?

The John Deere Construction 710 J was manufactured from 2007 to 2012.

How much does the John Deere Construction 710 J backhoe loader weigh?

The John Deere Construction 710 J backhoe loader weighs 10.45 tons.

What are the transport dimensions of the John Deere Construction 710 J backhoe loader?

The John Deere Construction 710 J has a transport length of 8.15 meters, a transport width of 2.29 meters, and a transport height of 2.97 meters.

What is the travel speed of the John Deere Construction 710 J backhoe loader?

The John Deere Construction 710 J has a travel speed of 39.6 km/h.

What are the standard tyre specifications for the undercarriage of the John Deere Construction 710 J backhoe loader?

The John Deere Construction 710 J is equipped with standard tyres sized Front: 14.5/75-16.1 SL F-3 and Rear: 21L-28 R-4.

What are the excavation performance specifications of the John Deere Construction 710 J backhoe loader?

The John Deere Construction 710 J has a dredging depth of 6.81 meters and a maximum horizontal reach of 9.46 meters.

What are the tear-out forces of the John Deere Construction 710 J backhoe loader?

The John Deere Construction 710 J has a tear-out force of 69.1 kN and a tear-out force for the backhoe of 75.6 kN.

What is the maximum discharge height of the John Deere Construction 710 J backhoe loader?

The John Deere Construction 710 J backhoe loader has a maximum discharge height of 5.18 meters.

What are the specifications of the primary work tool on the John Deere Construction 710 J backhoe loader?

The John Deere Construction 710 J features a bucket capacity of 1.24 cubic meters, a bucket width of 2.46 meters, and a backhoe bucket capacity of 0.31 cubic meters.
