110 John Deere Construction 110 Specifications & Technical Data (2008—2021)

The John Deere Construction 110 is a backhoe loader manufactured by John Deere Construction from 2008 to 2021. It has a weight of …

The John Deere Construction 110 is a backhoe loader manufactured by John Deere Construction from 2008 to 2021. It has a weight of 3.667 tons and a transport length of 6.599 meters. The tear-out force is 17.635 kilonewtons, and it can dredge up to a depth of 3.073 meters. The maximum discharge height is 2.567 meters, and it has a maximum reach horizontal of 0.635 meters. The travel speed of this backhoe loader is 26.1 kilometers per hour. It has a transport height of 2.725 meters. The tear-out force of the backhoe is 23.287 kilonewtons. Additionally, it is equipped with special equipment including a diesel particulate filter, forklift utility, and outrigger stabilizers.

Backhoe Loaders John Deere Construction 110

Technical specs - 110 John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.667 t
Standard tyres
F: 10x16.5 8PR R: 17.5Lx24 8PR
Drive
A
Transport length
6.599 m
Transport height
2.725 m
Tear-out force
17.635 kN
Tear-out force backhoe
23.287 kN
Max. Reach horizontal
0.635 m
Dredging depth
3.073 m
Max. discharge height
2.567 m
Travel speed
26.1 km/h
Engine manuf.
John Deere
Engine type
N/A
Engine power
32.1 kW
Displacement
2.2 l
No. of cylinders
4

More technical details, like: bucket width, bucket capacity, bucket capacity backhoe, transport width, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
Yes
Clamshell
No
Forklift utility
Yes
Grabber
No
Diesel particulate filter
Yes
Aircondition
No

Download datasheets (PDF)

John Deere Construction 110 FAQ

When was the John Deere Construction 110 backhoe loader manufactured?

The John Deere Construction 110 backhoe loader was manufactured from 2008 to 2021.

How much does the John Deere Construction 110 backhoe loader weigh?

The John Deere Construction 110 backhoe loader weighs 3.67 tons.

What are the transport dimensions of the John Deere Construction 110 backhoe loader?

The John Deere Construction 110 backhoe loader has a transport length of 6.6 meters and a transport height of 2.73 meters.

What is the travel speed of the John Deere Construction 110 backhoe loader?

The John Deere Construction 110 backhoe loader has a travel speed of 26.1 km/h.

What are the undercarriage specifications of the John Deere Construction 110 backhoe loader?

The John Deere Construction 110 backhoe loader has an all-wheel drive and standard tyres sized Front: 10x16.5 8PR and Rear: 17.5Lx24 8PR.

What are the excavation performance specifications of the John Deere Construction 110 backhoe loader?

The John Deere Construction 110 backhoe loader has a dredging depth of 3.073 meters and a maximum horizontal reach of 0.635 meters.

What are the tear-out forces of the John Deere Construction 110 backhoe loader?

The John Deere Construction 110 has a tear-out force of 17.635 kN and a backhoe tear-out force of 23.29 kN.

What is the maximum discharge height of the John Deere Construction 110 backhoe loader?

The John Deere Construction 110 backhoe loader has a maximum discharge height of 2.57 meters.
