5CX Pro JCB 5CX Pro Specifications & Technical Data (2021—2026)

The JCB 5CX Pro is a backhoe loader manufactured by JCB since 2021. It has a weight of 9.034 tons and a transport length of 5.91 m…

The JCB 5CX Pro is a backhoe loader manufactured by JCB since 2021. It has a weight of 9.034 tons and a transport length of 5.91 meters. The bucket capacity is 1.3 cubic meters, with a dredging depth of 4.93 meters and a bucket width of 2.36 meters. The maximum discharge height is 2.69 meters, and it has a maximum reach horizontal of 6.01 meters. The travel speed of this machine is 40 km/h. It has a transport width of 2.33 meters and a transport height of 3.97 meters. The special equipment included is an air conditioning system.

Backhoe Loaders JCB 5CX Pro
Backhoe Loaders JCB 5CX Pro
Backhoe Loaders JCB 5CX Pro
Backhoe Loaders JCB 5CX Pro

Visit JCB live at

Technical specs - 5CX Pro JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.034 t
Standard tyres
440/80-28
Bucket width
2.36 m
Bucket capacity
1.3 m³
Drive
A
Transport length
5.91 m
Transport width
2.33 m
Transport height
3.97 m
Max. Reach horizontal
6.01 m
Dredging depth
4.93 m
Max. discharge height
2.69 m
Travel speed
40 km/h
Model series
CX
Engine manuf.
JCB
Engine type
EcoMax
Engine power
81 kW
Displacement
4.8 l
Revolutions at max torque
1450 rpm
Max. torque
516 Nm
No. of cylinders
4
Cylinder bore x stroke
106x112 mm
Emission level
V

More technical details, like: bucket capacity backhoe, tear-out force, tear-out force backhoe, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
Yes
Aircondition
Yes

Download datasheets (PDF)

JCB 5CX Pro FAQ

When was the JCB 5CX Pro manufactured?

The JCB 5CX Pro was first produced in 2021.

How much does the JCB 5CX Pro weigh?

The JCB 5CX Pro weighs 9.03 tons.

What are the transport dimensions of the JCB 5CX Pro backhoe loader?

The JCB 5CX Pro has a transport length of 5.91 meters, a transport width of 2.33 meters, and a transport height of 3.97 meters.

What is the travel speed of the JCB 5CX Pro backhoe loader?

The JCB 5CX Pro backhoe loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the JCB 5CX Pro backhoe loader?

The JCB 5CX Pro backhoe loader features an all-wheel drive system and standard tyres sized 440/80-28.

What are the dredging depth and maximum horizontal reach of the JCB 5CX Pro?

The JCB 5CX Pro has a dredging depth of 4.93 meters and a maximum horizontal reach of 6.01 meters.

What is the material handling capacity of the JCB 5CX Pro in terms of discharge height?

The JCB 5CX Pro has a maximum discharge height of 2.69 meters.

What are the bucket specifications of the JCB 5CX Pro backhoe loader?

The JCB 5CX Pro backhoe loader has a bucket capacity of 1.3 cubic meters and a bucket width of 2.36 meters.

How much is a JCB 5CX Pro Backhoe loader (2021u20132025) worth?

The residual value of the JCB 5CX Pro depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
