3CX Eco JCB 3CX Eco Specifications & Technical Data (2009—2017)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Visit JCB live at
.jpg){kind=logo}
Technical specs - 3CX Eco JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 8.4 t
- Standard tyres
- 14.9/14 x 24. 12PR/14.9/14 x 24. 12PR
- Bucket width
- 2.23 m
- Bucket capacity
- 1 m³
- Drive
- A
- Transport length
- 5.91 m
- Transport width
- 2.24 m
- Transport height
- 3.56 m
- Tear-out force
- 53.3 kN
- Max. Reach horizontal
- 5.4 m
- Dredging depth
- 4.37 m
- Max. discharge height
- 2.64 m
- Model series
- CX
- Engine manuf.
- JCB
- Engine type
- 444
- Engine power
- 81 kW
- Displacement
- 4.4 l
- Revolutions at max torque
- 1300 rpm
- Max. torque
- 516 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 103x132 mm
More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, emission level are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
No
- Clamshell
-
No
- Forklift utility
-
No
- Grabber
-
No
- Diesel particulate filter
-
No
- Aircondition
-
No
