1CX JCB 1CX Specifications & Technical Data (2017—2020)

The JCB 1CX is a backhoe loader manufactured by JCB from 2017 to 2020. It has a weight of 3.16 tons and a transport length of 3.4 …

The JCB 1CX is a backhoe loader manufactured by JCB from 2017 to 2020. It has a weight of 3.16 tons and a transport length of 3.4 meters. The bucket capacity is 0.32 cubic meters, with a tear-out force of 23 kilonewtons. The dredging depth is 2.55 meters, and the bucket width is 1.58 meters. The maximum discharge height is 2.1 meters, and the maximum reach horizontal is 3.38 meters. The travel speed is 11 kilometers per hour. The transport width is 1.58 meters, and the transport height is 2.26 meters. The backhoe has a bucket capacity of 0.8 cubic meters and a tear-out force of 21.4 kilonewtons. The special equipment includes outrigger stabilizers.

Backhoe Loaders JCB 1CX
Backhoe Loaders JCB 1CX
Backhoe Loaders JCB 1CX
Backhoe Loaders JCB 1CX
Backhoe Loaders JCB 1CX
Backhoe Loaders JCB 1CX

Visit JCB live at

Technical specs - 1CX JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.16 t
Standard tyres
10x16.5
Bucket width
1.58 m
Bucket capacity
0.32 m³
Bucket capacity backhoe
0.8 m³
Drive
A
Transport length
3.4 m
Transport width
1.58 m
Transport height
2.26 m
Tear-out force
23 kN
Tear-out force backhoe
21.4 kN
Max. Reach horizontal
3.38 m
Dredging depth
2.55 m
Max. discharge height
2.1 m
Travel speed
11 km/h
Model series
CX
Engine manuf.
Perkins
Engine type
404C-22
Engine power
36.3 kW
Displacement
2.2 l
No. of cylinders
4

More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
Yes
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

JCB 1CX FAQ

When was the JCB 1CX backhoe loader manufactured?

The JCB 1CX backhoe loader was manufactured from 2017 to 2020.

How much does the JCB 1CX backhoe loader weigh?

The JCB 1CX backhoe loader weighs 3.16 tons.

What are the transport dimensions of the JCB 1CX backhoe loader?

The JCB 1CX backhoe loader has a transport length of 3.4 meters, a transport width of 1.58 meters, and a transport height of 2.26 meters.

What is the travel speed of the JCB 1CX backhoe loader?

The JCB 1CX backhoe loader has a travel speed of 11 km/h.

What are the undercarriage specifications of the JCB 1CX backhoe loader?

The JCB 1CX backhoe loader has an all-wheel drive system and is equipped with standard tyres sized 10x16.5.

What are the excavation performance specifications of the JCB 1CX backhoe loader?

The JCB 1CX backhoe loader has a dredging depth of 2.55 meters and a maximum horizontal reach of 3.38 meters.

What are the power ratings of the JCB 1CX backhoe loader?

The JCB 1CX has a tear-out force of 23 kN and a backhoe tear-out force of 21.4 kN.

What is the maximum discharge height of the JCB 1CX?

The JCB 1CX has a maximum discharge height of 2.1 meters.

What are the bucket specifications of the JCB 1CX backhoe loader?

The JCB 1CX has a front bucket capacity of 0.32 cubic meters, a bucket width of 1.58 meters, and a backhoe bucket capacity of 0.8 cubic meters.

How much is a JCB 1CX Backhoe loader (2017u20132020) worth?

The residual value of the JCB 1CX depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
