928F Hydrema 928F Specifications & Technical Data (2019—2026)

The Hydrema 928F is a backhoe loader manufactured by Hydrema since 2019. It has a weight of 9.4 tons and a bucket capacity of 1.7 …

The Hydrema 928F is a backhoe loader manufactured by Hydrema since 2019. It has a weight of 9.4 tons and a bucket capacity of 1.7 cubic meters. The tear-out force is 85 kilonewtons, and it can dredge up to a depth of 5.39 meters. The bucket width is 2.55 meters, and the maximum discharge height is 2.81 meters. It has a maximum reach horizontal of 6.5 meters. The transport width is 2.31 meters, and the transport height is 4.14 meters. This construction machine is equipped with special equipment including air conditioning, a clamshell, a forklift utility, a grabber, and outrigger stabilizers. The backhoe bucket capacity is 0.43 cubic meters, and it has a tear-out force of 38.4 kilonewtons.

Backhoe Loaders Hydrema 928F
Backhoe Loaders Hydrema 928F
Backhoe Loaders Hydrema 928F
Backhoe Loaders Hydrema 928F

Visit Hydrema live at

Technical specs - 928F Hydrema

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.4 t
Standard tyres
480/80x26”
Bucket width
2.55 m
Bucket capacity
1.7 m³
Bucket capacity backhoe
0.43 m³
Drive
A
Transport width
2.31 m
Transport height
4.14 m
Tear-out force
85 kN
Tear-out force backhoe
38.4 kN
Max. Reach horizontal
6.5 m
Dredging depth
5.39 m
Max. discharge height
2.81 m
Model series
F
Engine manuf.
Cummins
Engine type
QSB4.5
Engine power
108 kW
Displacement
4.5 l
Revolutions at max torque
1500 rpm
Max. torque
597 Nm
Emission level
IV

More technical details, like: transport length, travel speed, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
Yes
Clamshell
Yes
Forklift utility
Yes
Grabber
Yes
Diesel particulate filter
No
Aircondition
Yes

Download datasheets (PDF)

Hydrema 928F FAQ

When was the Hydrema 928F manufactured?

The Hydrema 928F was first produced in 2019.

How much does the Hydrema 928F weigh?

The Hydrema 928F weighs 9.4 tons.

What are the transport dimensions of the Hydrema 928F backhoe loader?

The Hydrema 928F has a transport width of 2.31 meters and a transport height of 4.14 meters.

What are the undercarriage specifications of the Hydrema 928F backhoe loader?

The Hydrema 928F backhoe loader features an all-wheel drive system and standard tyres sized 480/80x26 inches.

What are the excavation performance specifications of the Hydrema 928F backhoe loader?

The Hydrema 928F has a dredging depth of 5.39 meters and a maximum horizontal reach of 6.5 meters.

What are the tear-out forces of the Hydrema 928F backhoe loader?

The Hydrema 928F has a tear-out force of 85 kN and a backhoe tear-out force of 38.4 kN.

What is the maximum discharge height for material handling of the Hydrema 928F backhoe loader?

The Hydrema 928F backhoe loader has a maximum discharge height of 2.81 meters.

What are the specifications of the primary bucket on the Hydrema 928F backhoe loader?

The primary bucket of the Hydrema 928F has a capacity of 1.7 cubic meters and a width of 2.55 meters.

How much is a Hydrema 928F Backhoe loader (2019u20132025) worth?

The residual value of the Hydrema 928F depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
