908F Hydrema 908F Specifications & Technical Data (2019—2026)

The Hydrema 908F is a backhoe loader manufactured by Hydrema since 2019. It has a weight of 9.1 tons and a bucket capacity of 1.4 …

The Hydrema 908F is a backhoe loader manufactured by Hydrema since 2019. It has a weight of 9.1 tons and a bucket capacity of 1.4 cubic meters. The tear-out force is 73 kilonewtons, and it can dredge up to a depth of 5.44 meters. The bucket width is 2.38 meters, and the maximum discharge height is 2.89 meters. It has a maximum reach horizontal of 6.5 meters. The transport width is 2.3 meters, and the transport height is 4.14 meters. This construction machine is equipped with special equipment including air conditioning, a clamshell, a forklift utility, a grabber, and outrigger stabilizers. The backhoe bucket capacity is 0.43 cubic meters, and it has a tear-out force of 37.6 kilonewtons.

Backhoe Loaders Hydrema 908F
Backhoe Loaders Hydrema 908F
Backhoe Loaders Hydrema 908F
Backhoe Loaders Hydrema 908F

Visit Hydrema live at

Technical specs - 908F Hydrema

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.1 t
Standard tyres
500/70x24”
Bucket width
2.38 m
Bucket capacity
1.4 m³
Bucket capacity backhoe
0.43 m³
Drive
A
Transport width
2.3 m
Transport height
4.14 m
Tear-out force
73 kN
Tear-out force backhoe
37.6 kN
Max. Reach horizontal
6.5 m
Dredging depth
5.44 m
Max. discharge height
2.89 m
Model series
F
Engine manuf.
Cummins
Engine type
QSB4.5
Engine power
90 kW
Displacement
4.5 l
Revolutions at max torque
1500 rpm
Max. torque
470 Nm
Emission level
IV

More technical details, like: transport length, travel speed, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
Yes
Clamshell
Yes
Forklift utility
Yes
Grabber
Yes
Diesel particulate filter
No
Aircondition
Yes

Download datasheets (PDF)

Hydrema 908F FAQ

When was the Hydrema 908F manufactured?

The Hydrema 908F was first produced in 2019.

How much does the Hydrema 908F weigh?

The Hydrema 908F weighs 9.1 tons.

What are the transport dimensions of the Hydrema 908F backhoe loader?

The Hydrema 908F has a transport width of 2.3 meters and a transport height of 4.14 meters.

What are the undercarriage specifications of the Hydrema 908F backhoe loader?

The Hydrema 908F backhoe loader features an all-wheel drive system and standard tyres sized 500/70x24 inches.

What is the excavation performance of the Hydrema 908F backhoe loader?

The Hydrema 908F has a dredging depth of 5.44 meters and a maximum horizontal reach of 6.5 meters.

What are the tear-out forces of the Hydrema 908F backhoe loader?

The Hydrema 908F has a tear-out force of 73 kN and a backhoe tear-out force of 37.6 kN.

What is the maximum discharge height of the Hydrema 908F backhoe loader?

The Hydrema 908F backhoe loader has a maximum discharge height of 2.89 meters.

What are the specifications of the primary work tools on the Hydrema 908F backhoe loader?

The Hydrema 908F has a loader bucket with a capacity of 1.4 cubic meters and a width of 2.38 meters, and a backhoe bucket with a capacity of 0.43 cubic meters.
