Technical specs - 906F Hydrema
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 9.2 t
- Standard tyres
- 500/70x24”
- Bucket width
- 2.38 m
- Bucket capacity
- 1.4 m³
- Bucket capacity backhoe
- 0.35 m³
- Drive
- A
- Transport width
- 2.3 m
- Transport height
- 4.13 m
- Tear-out force
- 73 kN
- Tear-out force backhoe
- 37.6 kN
- Max. Reach horizontal
- 6.13 m
- Dredging depth
- 4.81 m
- Max. discharge height
- 2.93 m
- Model series
- F
- Engine manuf.
- Cummins
- Engine type
- QSB4.5
- Engine power
- 90 kW
- Displacement
- 4.5 l
- Revolutions at max torque
- 1500 rpm
- Max. torque
- 470 Nm
- Emission level
- IV
More technical details, like: transport length, travel speed, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
Yes
- Clamshell
-
Yes
- Forklift utility
-
Yes
- Grabber
-
Yes
- Diesel particulate filter
-
No
- Aircondition
-
Yes
