Technical specs - 906F Hydrema

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight 9.2 t
Standard tyres 500/70x24”
Bucket width 2.38 m
Bucket capacity 1.4 m³
Bucket capacity backhoe 0.35 m³
Drive A
Transport width 2.3 m
Transport height 4.13 m
Tear-out force 73 kN
Tear-out force backhoe 37.6 kN
Max. Reach horizontal 6.13 m
Dredging depth 4.81 m
Max. discharge height 2.93 m
Engine manuf. Cummins
Engine type QSB 4.5
Engine power 90 kW
Engine power 122 HP
Displacement 4.5 l
Revolutions at max torque 1500 rpm
Max. torque 470 Nm
Emission level IV
Transport length ###
Travel speed ###
Dimension lxwxh ###
No. of cylinders ###
Cylinder bore x stroke ###
Weight ###

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

906F Hydrema - Special equipment

  • Outrigger stabilisers
  • Clamshell
  • Forklift utility
  • Grabber
  • Diesel particulate filter
  • Aircondition
