Technical specs - HMK 102 S Supra Hidromek
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 9.725 t
- Standard tyres
- 16.9x28-12 PR
- Bucket width
- 2.44 m
- Bucket capacity
- 1.2 m³
- Bucket capacity backhoe
- 0.17 m³
- Drive
- A
- Transport length
- 6.09 m
- Transport width
- 2.292 m
- Transport height
- 3.6 m
- Tear-out force
- 76.14 kN
- Tear-out force backhoe
- 33.68 kN
- Max. Reach horizontal
- 6.854 m
- Dredging depth
- 5.703 m
- Max. discharge height
- 4.679 m
- Travel speed
- 40 km/h
- Engine manuf.
- Perkins
- Engine type
- 1204F-E44TAN
- Engine power
- 74.4 kW
- Displacement
- 4.4 l
- Revolutions at max torque
- 1400 rpm
- Max. torque
- 450 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 105x127 mm
- Emission level
- IV / Tier 4 Final
More technical details, like: model series, dimension lxwxh are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
No
- Clamshell
-
No
- Forklift utility
-
Yes
- Grabber
-
No
- Diesel particulate filter
-
No
- Aircondition
-
Yes
