E 245 K Eurocomach E 245 K Specifications & Technical Data (1999—2020)

The Eurocomach E 245 K is a backhoe loader manufactured from 1999 to 2020. It has a weight of 3.8 tons and a transport length of 4…

The Eurocomach E 245 K is a backhoe loader manufactured from 1999 to 2020. It has a weight of 3.8 tons and a transport length of 4.265 meters. The bucket capacity is 0.45 cubic meters, with a tear-out force of 36 kilonewtons. It can dredge up to a depth of 3 meters and has a bucket width of 1.45 meters. The maximum discharge height is 2.28 meters. The transport width and height are both 1.45 meters and 2.55 meters respectively. The tear-out force of the backhoe is 27.5 kilonewtons.

E 245 K

Years of manufacture: 1999—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - E 245 K Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.8 t

Standard tyres: 12x16.5

Bucket width: 1.45 m

Bucket capacity: 0.45 m³

Drive: A

Transport length: 4.265 m

Transport width: 1.45 m

Transport height: 2.55 m

Tear-out force: 36 kN

Tear-out force backhoe: 27.5 kN

Dredging depth: 3 m

Max. discharge height: 2.28 m

Model series: E

Engine manuf.: Kubota

Engine type: V2203M

Engine power: 35.6 kW

Displacement: 2.197 l

Revolutions at max torque: 1700 rpm

Max. torque: 95 Nm

No. of cylinders: 4

More technical details, like: bucket capacity backhoe, max. reach horizontal, travel speed, dimension lxwxh, cylinder bore x stroke, emission level, backhoe type, engine manufacturer, engine model, aspiration, diesel particulate filter, selective catalytic reduction, rated speed, engine output - gross, torque rated speed, torque, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, width, ground clearance, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, reach from slew pivot - non-extending dipper, loading height - non-extending dipper, dump height - general purpose, dump angle - general purpose, fuel tank, shovel capacity - standard general purpose, bucket tearout - non-extending dipper, shovel breakout - general purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Eurocomach E 245 K FAQ

When was the Eurocomach E 245 K manufactured?

The Eurocomach E 245 K was manufactured from 1999 to 2020.

How much does the Eurocomach E 245 K weigh?

The Eurocomach E 245 K weighs 3.8 tons.

What are the transport dimensions of the Eurocomach E 245 K backhoe loader?

The Eurocomach E 245 K has a transport length of 4.27 meters, a transport width of 1.45 meters, and a transport height of 2.55 meters.

What are the undercarriage specifications of the Eurocomach E 245 K backhoe loader?

The Eurocomach E 245 K backhoe loader has an all-wheel drive system and is equipped with standard tyres sized 12x16.5.

What is the dredging depth of the Eurocomach E 245 K backhoe loader?

The Eurocomach E 245 K backhoe loader has a dredging depth of 3 meters.

What are the tear-out forces of the Eurocomach E 245 K backhoe loader?

The Eurocomach E 245 K has a tear-out force of 36 kN and a backhoe tear-out force of 27.5 kN.

What is the material handling capacity of the Eurocomach E 245 K in terms of discharge height?

The Eurocomach E 245 K has a maximum discharge height of 2.28 meters.

What are the specifications of the bucket on the Eurocomach E 245 K backhoe loader?

The Eurocomach E 245 K has a bucket with a capacity of 0.45 cubic meters and a width of 1.45 meters.
