E 235 K Eurocomach E 235 K Specifications & Technical Data (1999—2010)

Model rating: 5,50 / 10

The Eurocomach E 235 K is a backhoe loader manufactured by Eurocomach from 1999 to 2010. It has a weight of 2.9 tons and a bucket …

The Eurocomach E 235 K is a backhoe loader manufactured by Eurocomach from 1999 to 2010. It has a weight of 2.9 tons and a bucket capacity of 0.42 cubic meters. The tear-out force of this machine is 26 kilonewtons, and it can dredge up to a depth of 2.85 meters. The transport width is 1.35 meters, and the transport height is 2.83 meters.

E 235 K

Years of manufacture: 1999—2010

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - E 235 K Eurocomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.9 t

Standard tyres: 10/75-15.3

Bucket capacity: 0.42 m³

Drive: A

Transport width: 1.35 m

Transport height: 2.83 m

Tear-out force: 26 kN

Dredging depth: 2.85 m

Model series: E

Engine manuf.: Kubota

Engine type: V2203

Engine power: 34 kW

Emission level: III/Tier 4i

More technical details, like: bucket width, bucket capacity backhoe, transport length, tear-out force backhoe, max. reach horizontal, max. discharge height, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, backhoe type, engine manufacturer, engine model, aspiration, rated speed, engine output - net, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, width, ground clearance, stabiliser type, maximum dig depth - longest dipper, reach from slew pivot - non-extending dipper, dump height - general purpose, dump angle - general purpose, fuel tank, shovel capacity - standard general purpose, bucket tearout - non-extending dipper, shovel breakout - general purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Eurocomach E 235 K FAQ

When was the Eurocomach E 235 K manufactured?

The Eurocomach E 235 K was manufactured from 1999 to 2010.

How much does the Eurocomach E 235 K backhoe loader weigh?

The Eurocomach E 235 K backhoe loader weighs 2.9 tons.

What are the transport dimensions of the Eurocomach E 235 K backhoe loader?

The Eurocomach E 235 K has a transport width of 1.35 meters and a transport height of 2.83 meters.

What are the undercarriage specifications of the Eurocomach E 235 K backhoe loader?

The Eurocomach E 235 K features an all-wheel drive system and comes with standard tyres sized 10/75-15.3.

What is the dredging depth of the Eurocomach E 235 K backhoe loader?

The Eurocomach E 235 K backhoe loader has a dredging depth of 2.85 meters.

What is the tear-out force of the Eurocomach E 235 K backhoe loader?

The Eurocomach E 235 K has a tear-out force of 26 kN.

What is the bucket capacity of the Eurocomach E 235 K backhoe loader?

The Eurocomach E 235 K backhoe loader has a bucket capacity of 0.42 cubic meters.
