    Case 695ST T 4 Specifications & Technical Data (2012-2017)

    Rate this machine now!

    The 695 ST T 4 backhoe loader model is manufactured by case. Find and download detailed specs and data sheets for this machine her... Read more

    The 695 ST T 4 backhoe loader model is manufactured by case. Find and download detailed specs and data sheets for this machine here.

    This backhoe loader is built to provide up to 82kW or 109 horse power, delivered from its powerful CNH engine to the 8.84t 695 ST T 4 machine. The 695 ST T 4 is categorised in the biggest machine segment in the backhoe loaders category. The model's dimensions are 5.75m x 2.4m x 2.9m. The bucket of 695 ST T 4 has a capacity of 1.2m³ which is average for this type of machine.

    Clamshell, Outrigger stabilisers and Diesel particulate filter are not provided on this model as of 2017. There are more detailed specifications and machine descriptions available in the original case 695 ST T 4 specs data sheet. Download a free data sheet in Spanish, French, Italian and English from LECTURA Specs.

    The production is still going in 2017, where this 695 ST T 4 is available at a new list price between €98000 and €124000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    Case currently produces 5 other backhoe loaders, which range from 8.1t up to 9.4t - the most visited on LECTURA Specs are 590 ST T4, 580 ST T4, 580 ST T4F. Ranked in the LECTURA index at #19, this 695 ST T 4 backhoe loader has models that date from 2012 to 2017. Want more detailed specifications? Download the latest case 695 ST T 4 specs data sheet on LECTURA Specs today!

    Technical specs - 695ST T 4 Case

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 8.84 t
    • Standard tyres 16.9x24
    • Bucket width 2.4 m
    • Bucket capacity 1.2 m³
    • Bucket capacity backhoe 0.32 m³
    • Drive A
    • Transport length 5.75 m
    • Transport width 2.4 m
    • Transport height 2.9 m
    • Tear-out force 40.62 kN
    • Tear-out force backhoe 61.14 kN
    • Travel speed 40 km/h
    • Engine manuf. CNH
    • Engine type 445TA-EGH
    • Engine power 82 kW
    • Displacement 4.5 l
    • Revolutions at max torque 1400 rpm
    • Emission level TIER 4i
    • Max. Reach horizontal ###
    • Dredging depth ###
    • Max. discharge height ###
    • Dimension lxwxh ###
    • Max. torque ###
    • No. of cylinders ###
    • Cylinder bore x stroke ###
    • Backhoe Type ###
    • Telematics Available ###
    • Platform ###
    • Engine Manufacturer ###
    • Engine Model ###
    • Emission Rating ###
    • Aspiration ###
    • Rated Speed ###
    • Engine Output - Net ###
    • Torque ###
    • Transmission Type ###
    • Number Of Travel Speeds ###
    • Drive - 2WD / 4WD ###
    • Service Brake Type ###
    • Length - Roading ###
    • Height - Over Cab ###
    • Maximum Height ###
    • Width ###
    • Width - Standard Shovel ###
    • Stabiliser Type ###
    • Maximum Dig Depth - Longest Dipper ###
    • Reach From Slew Pivot - Non-Extending Dipper ###
    • Reach From Slew pivot - Retracted Dipper ###
    • Reach From Slew Pivot - Extended Dipper ###
    • Loading Height - Non-Extending Dipper ###
    • Loading Height - Retracted Dipper ###
    • Loading Height - Extended Dipper ###
    • Dump Height - General Purpose ###
    • Dump Angle - General Purpose ###
    • Dump Height - Multi-Purpose ###
    • Dump Angle - Multi-Purpose ###
    • Fuel Tank ###
    • Shovel Capacity - Standard General Purpose ###
    • Shovel Capacity - Multi-Purpose ###
    • Bucket Tearout - Non-Extending Dipper ###
    • Dipper Tearout - Non-Extending Dipper ###
    • Shovel Breakout - General Purpose ###
    • Shovel Breakout - Multi-Purpose ###
    • Operating Weight ###

    Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

    Special equipment

    • Outrigger stabilisers
    • Clamshell
    • Forklift utility
    • Grabber
    • Diesel particulate filter
    • Aircondition
