Hammer
Maximize production and minimize costs
The BXR Series uses recoil sensing technology with operator actuated two-speed control and an oversized piston. This combination maximizes blow energy and bpm’s under varying rock conditions. For example, in hard rock conditions, the bpm’s are increased providing up to 80% operating efficiency versus 50% efficiency of a conventional breaker. Available on models BX15 up to BXR160; a lubrication system provides a constant supply of grease to the tool and bushing, prolonging component life. Available on models BX20 up to BXR160; a severe duty wear package protects the breaker housing in abrasive raking applications.
BX Series
Breaker mounted manual high/low stroke selector (BX8-BX40); improves production capability. Long stroke piston design; provides high levels of constant blow energy. Pressure balanced piston; optimizes bpm’s and blow energy. Anti-blank fire on/off selector (BX8-BX40); alternate modes when operating in varying rock conditions. Optimal sound dampening (BX6-BX40); further lowers noise levels, pertinent in high density population areas.
BXR Series
Two speed hydraulic pilot power control; controls blow energy in varying material conditions. Oil regeneration system; increases bpm’s without decreasing energy in harder material applications. High volume nitrogen charged accumulator; provides constant blow energy and recoil absorption. Extra-long stroke pressure balanced piston in conjunction with oil regeneration system; optimizes impact energy and bpm’s. Button nose piston design; maximizes energy transfer to the tool. Anti-blank fire interlock; protects front head and retainer pins.
