DSG 70 LST DSG 70 Specifications & Technical Data (2004—2006)

Grabber capacity: 0.5m³ – Closing force: 29kN – Height: 1330mm – Width: 600mm – Opening width: 1830mm – Max. pressure: 320bar

Attachments Demolition Sorting Grabs LST DSG 70

Technical specs - DSG 70 LST

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Grabber capacity
0.5 m³
Closing force
29 kN
Height
1330 mm
Width
600 mm
Opening width
1830 mm
Max. pressure
320 bar
Weight
0.82 t
Model series
DSG

Basic model without hoselines and adapter for excavator

Special equipment

endless rotation
No
Hydr. grabber rotating mechanism
No
Piston rod protections
No
Quick hitch mech.
No
