D 16 H-P 90 HD Kinshofer D 16 H-P 90 HD Specifications & Technical Data (2002—2012)
Visit Kinshofer live at
Technical specs - D 16 H-P 90 HD Kinshofer
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Grabber capacity
- 0.415 m³
- Carrying device
- 12-16 t
- Closing force
- 43 kN
- Height
- 1306 mm
- Width
- 900 mm
- Opening width
- 1730 mm
- Max. pressure
- 350 bar
- Weight
- 0.84 t
- Model series
- D
Basic model without hoselines and adapter for excavator
Special equipment
- endless rotation
-
Yes
- Hydr. grabber rotating mechanism
-
Yes
- Piston rod protections
-
No
- Quick hitch mech.
-
No
