2406J-E13TA Perkins 2406J-E13TA Specifications & Technical Data (2019—2026)

The Perkins 2406J-E13TA engine, manufactured since 2019, is a 12.5 liter machine component weighing 1125 kilograms. It features 6 …

The Perkins 2406J-E13TA engine, manufactured since 2019, is a 12.5 liter machine component weighing 1125 kilograms. It features 6 cylinders with a bore of 130 mm and a stroke of 157 mm. With a maximum torque of 2634 Nm, it operates at a maximum power of 430 kW and a minimum power of 340 kW at 1800 RPM.

Technical specs - 2406J-E13TA Perkins

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
6
Displacement
12.5 l
Layout
Inline
min. Power
340 kW
max. Power
430 kW
RPM
1800
Max. torque
2634 Nm
Tier Max.
EU V / US T4f
Aspiration
T
Weight
1125 kg
Type of cooling
w
Bore
130 mm
Stroke
157 mm
Model series
2400

More technical details, like: tier min., alternative name are available in the full technical specs.

Download datasheets (PDF)

Perkins 2406J-E13TA overview

Torque

Rating definitions and conditions

IND-A (Continuous) for heavy duty service where the engine is operated at maximum power and speed up to 100% of the time without interruption or load cycling. IND-B for service where power and/or speed are cyclic (time at full load not to exceed 80%). IND-C (Intermittent) is the horsepower and speed capability of the engine where maximum power and/or speed are cyclic (time at full load not to exceed 50%). IND-D for service where maximum power is required for periodic overloads (time at full load not to exceed 10% of the duty cycle).
