6090HFC94 John Deere Construction 6090HFC94 Specifications & Technical Data (2017—2026)

The John Deere Construction 6090HFC94 is a machine component manufactured since 2017. It has a displacement of 9 liters and weighs…

The John Deere Construction 6090HFC94 is a machine component manufactured since 2017. It has a displacement of 9 liters and weighs 1095.5 kilograms. With 6 cylinders and a bore of 118.4 mm, it has a stroke of 136 mm. The engine has a maximum torque of 1305 Nm and operates at a maximum power of 224 kW. It also has a minimum power of 186 kW and operates at a speed of 2200 RPM.

Engines John Deere Construction 6090HFC94

Technical specs - 6090HFC94 John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
6
Displacement
9 l
Layout
inline
min. Power
186 kW
max. Power
224 kW
RPM
2200
Max. torque
1305 Nm
Tier Max.
Tier 4 / IIIB
Aspiration
T
Weight
1095.5 kg
Bore
118.4 mm
Stroke
136 mm

More technical details, like: tier min., type of cooling, alternative name, model series are available in the full technical specs.
