4045HFC09 John Deere Construction 4045HFC09 Specifications & Technical Data (2017—2026)

The John Deere Construction 4045HFC09 engine, manufactured since 2017, is a 4.5-liter displacement machine component. It weighs 57…

The John Deere Construction 4045HFC09 engine, manufactured since 2017, is a 4.5-liter displacement machine component. It weighs 570 kilograms and has a maximum torque of 667 Nm. With four cylinders, it has a bore of 106 mm and a stroke of 127 mm. The engine has a minimum power of 116 kW and a maximum power of 129 kW, operating at a speed of 2400 RPM.

Engines John Deere Construction 4045HFC09

Technical specs - 4045HFC09 John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
4
Displacement
4.5 l
Layout
inline
min. Power
116 kW
max. Power
129 kW
RPM
2400
Max. torque
667 Nm
Tier Max.
Tier 4
Aspiration
T
Weight
570 kg
Bore
106 mm
Stroke
127 mm

More technical details, like: tier min., type of cooling, alternative name, model series are available in the full technical specs.
