4H50TIC Hatz 4H50TIC Specifications & Technical Data (2018—2026)

The Hatz 4H50TIC engine, manufactured since 2018, is a machine component with a displacement of 1.952 liters and a weight of 348 k…

The Hatz 4H50TIC engine, manufactured since 2018, is a machine component with a displacement of 1.952 liters and a weight of 348 kilograms. It features four cylinders with a bore of 84 mm and a stroke of 88 mm. The engine has a maximum torque of 240 Nm and operates at a maximum power of 55 kW, with a minimum power of 37 kW. It runs at a speed of 2800 RPM.

Engines Hatz 4H50TIC

Technical specs - 4H50TIC Hatz

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
4
Displacement
1.952 l
Layout
Inline
min. Power
37 kW
max. Power
55 kW
RPM
2800
Max. torque
240 Nm
Tier Max.
Tier 4f
Aspiration
T
Weight
348 kg
Type of cooling
w
Bore
84 mm
Stroke
88 mm
Model series
H

More technical details, like: tier min., alternative name are available in the full technical specs.
