1D90V Hatz 1D90V Specifications & Technical Data (2017—2026)

The Hatz 1D90V engine, manufactured since 2017, is a machine component with a displacement of 0.722 liters and a weight of 106 kil…

The Hatz 1D90V engine, manufactured since 2017, is a machine component with a displacement of 0.722 liters and a weight of 106 kilograms. It features a single cylinder with a bore of 104 millimeters and a stroke of 85 millimeters. The engine has a maximum torque of 40.7 Nm and operates at a maximum speed of 3000 RPM. It has a minimum power output of 5.8 kW and a maximum power output of 11.2 kW.

Engines Hatz 1D90V

Technical specs - 1D90V Hatz

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
1
Displacement
0.722 l
Layout
Inline
min. Power
5.8 kW
max. Power
11.2 kW
RPM
3000
Max. torque
40.7 Nm
Tier Max.
Tier 4f
Weight
106 kg
Type of cooling
l
Bore
104 mm
Stroke
85 mm
Model series
D

More technical details, like: tier min., aspiration, alternative name are available in the full technical specs.
