TCD 2015 V6 Deutz TCD 2015 V6 Specifications & Technical Data (2004—2026)

The Deutz TCD 2015 V6 engine, manufactured since 2004, is a machine component with a displacement of 11.9 liters and a weight of 1…

The Deutz TCD 2015 V6 engine, manufactured since 2004, is a machine component with a displacement of 11.9 liters and a weight of 1020 kilograms. It has a maximum torque of 2080 Nm and is equipped with 6 cylinders. The bore measures 132 mm, while the stroke is 145 mm. With a maximum power output of 360 kW, this engine operates at a speed of 2100 RPM.

Technical specs - TCD 2015 V6 Deutz

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
6
Displacement
11.9 l
Layout
Vee
max. Power
360 kW
RPM
2100
Max. torque
2080 Nm
Tier Min.
EU II
Tier Max.
EU III
Aspiration
T
Weight
1020 kg
Type of cooling
w
Bore
132 mm
Stroke
145 mm
Model series
TCD

More technical details, like: min. power, alternative name are available in the full technical specs.

Download datasheets (PDF)

Deutz TCD 2015 V6 overview

Cool

Engine Features

Water-cooled V6 and V8 engines with turbocharging, charge air cooling and four-valve technology. Very compact engine design reduces the installation costs. Wet cylinder liners, long oil change intervals and easy changing of the engine fluids reduce the running and service costs and increase the availability of the machinery. Best cold starting properties even under extreme conditions. Low noise emissions due to acoustically optimized components with very smooth running and high durability. Electronic, solenoid valve-controlled DEUTZ MV-System® (pump-line-nozzle) ensures optimum engine performance at low consumption. The robust engine design allows worldwide operation even with high sulphur fuels. The V6 is also available as a flat version for extremely compact installations.
