F 4 L 914 Deutz F 4 L 914 Specifications & Technical Data (2015—2026)

The Deutz F 4 L 914 engine, manufactured since 2015, is a machine component with a displacement of 4.3 liters and a weight of 307 …

The Deutz F 4 L 914 engine, manufactured since 2015, is a machine component with a displacement of 4.3 liters and a weight of 307 kilograms. It features 4 cylinders with a bore of 102 mm and a stroke of 132 mm. The engine delivers a maximum torque of 270 Nm and a maximum power of 61.5 kW at 2500 RPM.

Technical specs - F 4 L 914 Deutz

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
4
Displacement
4.3 l
Layout
Inline
max. Power
61.5 kW
RPM
2500
Max. torque
270 Nm
Tier Max.
EU II / US T2
Aspiration
N
Weight
307 kg
Type of cooling
l
Bore
102 mm
Stroke
132 mm
Model series
F

More technical details, like: min. power, tier min., alternative name are available in the full technical specs.

Download datasheets (PDF)

Deutz F 4 L 914 overview

Cool

Engine Specifications

Air-cooled 3 to 6-cylinder naturally aspirated engines in inline arrangement. 4 and 6 cylinder engines also with turbocharging and optional electronic engine control (EMR) for easy integration into electronic equipment control and monitoring. The 6 cylinder engine with turbocharging is also available with charge air cooling. Easy, inexpensive installation due to minimum weight and small installation space. Low noise emissions due to acoustically optimized components with very smooth running and high durability. The robust engine design allows worldwide operation even with high sulphur fuels. Highly efficient injection and combustion system ensures optimum engine performance at low consumption. Best cold starting performance even under extreme conditions.
