D 914 L3 Deutz D 914 L3 Specifications & Technical Data (2011—2026)

The Deutz D 914 L3 engine, manufactured since 2011, is a machine component with a displacement of 3.2 liters and a weight of 277 k…

The Deutz D 914 L3 engine, manufactured since 2011, is a machine component with a displacement of 3.2 liters and a weight of 277 kilograms. It has a maximum torque of 204 Nm and is equipped with three cylinders. The bore measures 102 mm, while the stroke is 132 mm. With a maximum power output of 43 kW, this engine operates at a speed of 2300 RPM.

Engines Deutz D 914 L3

Technical specs - D 914 L3 Deutz

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
3
Displacement
3.2 l
Layout
Inline
max. Power
43 kW
RPM
2300
Max. torque
204 Nm
Tier Min.
EU II / US T2
Tier Max.
EU IIIA / US T3
Aspiration
N
Weight
277 kg
Bore
102 mm
Stroke
132 mm
Model series
D

More technical details, like: min. power, type of cooling, alternative name are available in the full technical specs.

Download datasheets (PDF)

Deutz D 914 L3 overview

Cool

Engine Specifications

Air-cooled 3 to 6-cylinder naturally aspirated engines in inline arrangement. 6-cylinder with turbocharging, charge-air cooled. Capacity: 1.1 l/cylinder, modular system with single cylinders. The robust engine design allows worldwide operation even with high sulphur fuels. Low noise emissions due to acoustically optimized components with very smooth running and high durability. Highly efficient injection and combustion system ensures optimum engine performance at low consumption. Flywheel and end 100% power takeoff possibilities PTO drives for hydraulic pumps and compressor possible, only a few maintenance points, long oil change intervals. Very compact engine design reduces the installation costs. Best cold starting properties even under extreme conditions. The engines in the power range < 56 kW meets to the US EPA Tier 4 i.
