1770 CX Weidemann 1770 CX Specifications & Technical Data (2008—2015)

Weight: 2.81t – Standard tyres: 10.0/75-15.3 AS ET40 – Steering mode: KL – Max. discharge height: 2.283m – Turning radius outside: 3.011m – Transport length: 4.719m

1770 CX

Years of manufacture: 2008—2015

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - 1770 CX Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.81 t

Standard tyres: 10.0/75-15.3 AS ET40

Steering mode: KL

Max. discharge height: 2.283 m

Turning radius outside: 3.011 m

Transport length: 4.719 m

Transport width: 1.124 m

Transport height: 2.225 m

Engine manuf.: Perkins

Engine type: 404D-22

Engine power: 36 kW

Displacement: 2.216 l

Revolutions at max torque: 2600 rpm

More technical details, like: operating weight, tipping load, wheel base, travel speed, max. height at the shovel pivot point, overcharging height, turning radius inside, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, engine model, aspiration, rated speed, engine output - net, transmission type, tyre - size, wheelbase, length - shovel on ground, height - over cab, ground clearance, width - over tyres, shovel - type, shovel - width, full lift dump height, full lift reach, loader - arm type, loader - geometry, dump angle - at dump, dump angle - maximum, height - pivot pin, full lift dump height - maximum, height - maximum, dig depth, turning radius - over shovel, fuel tank, straight tipping load, full turn tipping load, operating weight are available in the full technical specs.

Buy full specs

Special equipment

Cabin: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Weidemann 1770 CX FAQ

When was the Weidemann 1770 CX manufactured?

The Weidemann 1770 CX was manufactured from 2008 to 2015.

What is the weight of the Weidemann 1770 CX?

The Weidemann 1770 CX has a weight of 2.81 tonnes.

What are the physical dimensions of the Weidemann 1770 CX yard loader?

The Weidemann 1770 CX has a transport length of 4.72 meters, a transport width of 1.12 meters, and a transport height of 2.23 meters.

What are the maneuverability specifications of the Weidemann 1770 CX?

The Weidemann 1770 CX features articulated-frame steering and has an outside turning radius of 3.011 meters.

What are the wheel and tyre specifications of the Weidemann 1770 CX?

The Weidemann 1770 CX is equipped with standard tyres sized 10.0/75-15.3 AS ET40.

What is the maximum discharge height of the Weidemann 1770 CX yard loader?

The Weidemann 1770 CX has a maximum discharge height of 2.28 meters.

How much is a Weidemann 1770 CX Yard loader (2008u20132015) worth?

The residual value of the Weidemann 1770 CX depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Weidemann 1770 CX overview

Drive

Standard features

Engine Perkins 404 D-22 (35.7 kW / 49 hp) Drive PA940 planetary axle Hydrostatic all-wheel drive, travel direction can be selected via joystick Service brake: Hydrostatic drive system acting on all 4 wheels (wear-free) Central service and parking brake in the drive train acting on all 4 wheels 100% differential lock, electric-hydraulically connectable on front and rear axle Tyres 10.0 / 75 - 15.3 AS ET40 Steering Hydraulic articulated pendulum steering, 12° oscillating angle Hydraulics 3rd control circuit front DN12 Hydraulic oil cooler Lock for steering valve Floating position for lift and tilting cylinders Driver's cab Canopy with retaining system ROPS / FOPS tested, driver's cab can be tilted to the side Comfort seat with safety belt, fully suspended, weight, back and horizontal adjustment Joystick with direction control switch and integrated touch button for differential lock Adjustable steering column Other Working lights (2 front, 2 rear) Operating hour meter Battery circuit breaker Fuel display Hydraulic quick-change system for attachments
