1280 Weidemann 1280 Specifications & Technical Data (2019—2026)

Weight: 2.38t – Standard tyres: 10.0/75-15.3 AS ET 80 – Tipping load: 1385kg – Wheel base: 1.623m – Travel speed: 20km/h – Steering mode: KL

1280

Years of manufacture: 2019—2026

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - 1280 Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.38 t

Standard tyres: 10.0/75-15.3 AS ET 80

Tipping load: 1385 kg

Wheel base: 1.623 m

Travel speed: 20 km/h

Steering mode: KL

max. height at the shovel pivot point: 2.872 m

Overcharging height: 2.544 m

Max. discharge height: 2.067 m

Turning radius outside: 2.846 m

Turning radius inside: 1.423 m

Transport length: 3.321 m

Transport width: 1.044 m

Transport height: 2.255 m

Engine manuf.: Perkins

Engine type: 403J-17

Engine power: 18.4 kW

Displacement: 1.496 l

Revolutions at max torque: 1800 rpm

Max. torque: 90.4 Nm

Emission level: V

More technical details, like: operating weight, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Weidemann 1280 FAQ

When was the Weidemann 1280 manufactured?

The Weidemann 1280 was first produced in 2019.

What is the weight of the Weidemann 1280 yard loader?

The Weidemann 1280 yard loader has a weight of 2.38 tonnes.

What are the physical dimensions of the Weidemann 1280 yard loader?

The Weidemann 1280 has a transport length of 3.32 meters, a transport width of 1.04 meters, and a transport height of 2.26 meters.

What is the travel speed of the Weidemann 1280 yard loader?

The Weidemann 1280 yard loader has a travel speed of 20 km/h.

What are the maneuverability specifications of the Weidemann 1280 yard loader?

The Weidemann 1280 yard loader features articulated-frame steering with an outside turning radius of 2.846 meters and an inside turning radius of 1.423 meters.

What are the standard tyre specifications for the Weidemann 1280?

The Weidemann 1280 is equipped with standard tyres sized 10.0/75-15.3 AS ET 80.

What is the wheelbase of the Weidemann 1280 yard loader?

The Weidemann 1280 yard loader has a wheelbase of 1.623 meters.

What is the tipping load capacity of the Weidemann 1280?

The Weidemann 1280 has a tipping load capacity of 1385 kilograms.

What are the working height and reach specifications of the Weidemann 1280 yard loader?

The Weidemann 1280 has an overcharging height of 2.54 meters, a maximum discharge height of 2.07 meters, and a maximum height at the shovel pivot point of 2.87 meters.
