1160 Weidemann 1160 Specifications & Technical Data (2015—2022)

Weight: 2.35t – Standard tyres: 10.0/75-15.3 AS ET 10 – Tipping load: 1509kg – Wheel base: 1.468m – Travel speed: 15km/h – Steering mode: KL

1160

Years of manufacture: 2015—2022

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 1160 Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.35 t

Standard tyres: 10.0/75-15.3 AS ET 10

Tipping load: 1509 kg

Wheel base: 1.468 m

Travel speed: 15 km/h

Steering mode: KL

max. height at the shovel pivot point: 2.76 m

Overcharging height: 2.441 m

Max. discharge height: 1.819 m

Turning radius outside: 2.592 m

Turning radius inside: 1.017 m

Transport length: 3.005 m

Transport width: 1.044 m

Transport height: 2.257 m

Engine manuf.: k.A.

Engine type: Elektro

Engine power: 6.5 kW

More technical details, like: operating weight, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, engine model, transmission type, transmission manufacturer, motor - type, traction control, tyre - size, wheelbase, length - shovel on ground, height - over cab, ground clearance, width - over tyres, shovel - type, shovel - width, full lift dump height, full lift reach, loader - arm type, loader - geometry, dump angle - at dump, dump angle - maximum, height - pivot pin, full lift dump height - maximum, height - maximum, dig depth, turning radius - over shovel, straight tipping load, operating weight are available in the full technical specs.

Special equipment

Cabin: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: Yes

Download datasheets (PDF)

1160 Weidemann Specification for Europe (DE)

Weidemann 1160 FAQ

When was the Weidemann 1160 manufactured?

The Weidemann 1160 was manufactured from 2015 to 2022.

What is the weight of the Weidemann 1160 yard loader?

The Weidemann 1160 yard loader has a weight of 2.35 tonnes.

What are the physical dimensions of the Weidemann 1160 yard loader?

The Weidemann 1160 has a transport length of 3.01 meters, a transport width of 1.04 meters, and a transport height of 2.26 meters.

What is the travel speed of the Weidemann 1160 yard loader?

The Weidemann 1160 has a travel speed of 15 km/h.

What are the maneuverability specifications of the Weidemann 1160 yard loader?

The Weidemann 1160 features articulated-frame steering with an outside turning radius of 2.592 meters and an inside turning radius of 1.017 meters.

What are the standard tyre specifications for the Weidemann 1160?

The Weidemann 1160 comes equipped with standard tyres sized 10.0/75-15.3 AS ET 10.

What is the wheelbase of the Weidemann 1160 yard loader?

The Weidemann 1160 has a wheelbase of 1.468 meters.

What is the mass capacity of the Weidemann 1160?

The Weidemann 1160 has a tipping load capacity of 1509 kilograms.

What are the working height and reach specifications of the Weidemann 1160 yard loader?

The Weidemann 1160 has an overcharging height of 2.44 meters, a maximum discharge height of 1.82 meters, and a maximum height at the shovel pivot point of 2.76 meters.
