Technical specs - 1140 Weidemann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.63 t
- Standard tyres
- 7.00-12 AS ET 40
- Tipping load
- 664 kg
- Wheel base
- 1.345 m
- Travel speed
- 12 km/h
- Steering mode
- KL
- max. height at the shovel pivot point
- 2.73 m
- Overcharging height
- 2.41 m
- Max. discharge height
- 1.81 m
- Turning radius outside
- 2.14 m
- Turning radius inside
- 0.6 m
- Transport length
- 2.73 m
- Transport width
- 0.85 m
- Transport height
- 2.12 m
- Engine manuf.
- Perkins
- Engine type
- 403J-11
- Engine power
- 18.4 kW
- Displacement
- 1.496 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 90.4 Nm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: operating weight, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Special equipment
- Cabin
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
Yes
