Technical specs - 1140 Weidemann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.63 t
- Standard tyres
- 7.00-12 AS ET 40
- Tipping load
- 664 kg
- Wheel base
- 1.345 m
- Travel speed
- 12 km/h
- Steering mode
- KL
- max. height at the shovel pivot point
- 2.73 m
- Overcharging height
- 2.41 m
- Max. discharge height
- 1.81 m
- Turning radius outside
- 2.14 m
- Turning radius inside
- 0.6 m
- Transport length
- 2.73 m
- Transport width
- 0.85 m
- Transport height
- 2.12 m
- Engine manuf.
- Perkins
- Engine type
- 403J-11
- Engine power
- 18.4 kW
- Displacement
- 1.496 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 90.4 Nm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: operating weight, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Special equipment
- Cabin
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
Yes
Download datasheets (PDF)
Weidemann 1140 FAQ
What is the weight of the Weidemann 1140 yard loader?
What are the transport dimensions of the Weidemann 1140 yard loader?
What is the travel speed of the Weidemann 1140 yard loader?
What are the maneuverability specifications of the Weidemann 1140 yard loader?
What are the standard tyre specifications for the Weidemann 1140?
What is the wheelbase of the Weidemann 1140 yard loader?
What is the tipping load capacity of the Weidemann 1140?
What are the working height and reach specifications of the Weidemann 1140 yard loader?
