Technical specs - 3348 L-5A Thaler

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.5 t

Standard tyres: 400/50-15 AS

Tipping load: 1900 kg

Wheel base: 1.95 m

Travel speed: 20 km/h

Steering mode: KL/A

max. height at the shovel pivot point: 2.765 m

Max. discharge height: 1.99 m

Turning radius outside: 2.42 m

Turning radius inside: 0.76 m

Transport length: 3.34 m

Transport width: 1.66 m

Transport height: 2.26 m

Engine manuf.: Yanmar

Engine type: k.A.

Engine power: 35.4 kW

Displacement: 2.22 l

Revolutions at max torque: 3000 rpm

No. of cylinders: 4

Emission level: IIIA

More technical details, like: operating weight, overcharging height, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Thaler 3348 L-5A FAQ

When was the Thaler 3348 L-5A manufactured?

The Thaler 3348 L-5A was manufactured from 2019 to 2020.

What is the weight of the Thaler 3348 L-5A?

The Thaler 3348 L-5A has a weight of 2.5 tonnes.

What are the physical dimensions of the Thaler 3348 L-5A yard loader?

The Thaler 3348 L-5A has a transport length of 3.34 meters, a transport width of 1.66 meters, and a transport height of 2.26 meters.

What is the travel speed of the Thaler 3348 L-5A?

The Thaler 3348 L-5A has a travel speed of 20 km/h.

What are the maneuverability specifications of the Thaler 3348 L-5A?

The Thaler 3348 L-5A features all-wheel, articulated-frame steering with an outside turning radius of 2.42 meters and an inside turning radius of 0.76 meters.

What are the tyre specifications for the Thaler 3348 L-5A?

The Thaler 3348 L-5A is equipped with standard tyres sized 400/50-15 AS.

What is the wheel base of the Thaler 3348 L-5A?

The Thaler 3348 L-5A has a wheel base of 1.95 meters.

What is the mass capacity of the Thaler 3348 L-5A?

The Thaler 3348 L-5A has a tipping load capacity of 1900 kilograms.

What are the maximum discharge height and the maximum height at the shovel pivot point of the Thaler 3348 L-5A?

The Thaler 3348 L-5A has a maximum discharge height of 1.99 meters and a maximum height at the shovel pivot point of 2.77 meters.
